CORDLESS: 14.4-VOLT MICROLITHIUM PLATFORMS POWER

CDRR761K2
CDRS761K2
CDRR761 Series 14.4 V MicroLithium 3/8ʺ
CDR761 Series 14.4 V 3/8ʺ Capacity Drills Capacity Right-Angle Drills TOOLS
Specifications CDRS761K2 Specifications CDRR761K2
Battery Type MicroLithium 2.5 Ah Battery Type MicroLithium 2.5 Ah
Battery Voltage 14.4 Battery Voltage 14.4
Charge Time, minutes 70 Charge Time, minutes 70
Chuck Capacity, inches (mm) 3/8 (9.5) Chuck Cap., inches (mm) 3/8 (10)
Clutch Settings 9 Torque Output, in-lb (N•m) 150 (16.9)
Torque Output, in-lb (N•m) 65 (7.3) Free Speed (RPM), Low (High) 0–450 (0–1,550)
Free Speed, RPM 0–1,350 Clutch Settings 9
Sound Pressure Level, dB(A) 80.4 Sound Power Level, dB(A) 85.3
Vibration Level, m/s 2 1.3 Sound Pressure Level, dB(A) 73.7
Length, inches (mm) 13.3 (337.8) Length, inches (mm) 13.3 (337.8)
Height, inches (mm) 3.3 (83.8) Height, inches (mm) 7.8 (198.1)
Width, inches (mm) 2 (50.8) Width, inches (mm) 1.9 (48.5)
Weight with Battery, lb (kg) 2.6 (1.2) Weight with Battery, lb (kg) 3.1 (1.4)
Warranty (battery) 1 Year Warranty (battery) 1 Year
Warranty (tool and charger) 1 Year Warranty (tool and charger) 1 Year
Battery (qty) CTB8174 (2) Battery (Quantity) CTB8174 (2)
Charger CTC772A Battery Charger CTC772A
Tool Only CDRS761DB Tool Only CDRR761DB
CDRS761K2 14.4 V MicroLithium Cordless Inline Drill Kit CDRR761K2 14.4 V 3/8ʺ MicroLithium Cordless Right
• 65 in-lb of torque output to get the job done Angle Screw Gun/Drill Kit
• 0–1,350 RPM free speed • 150 in-lb of torque handles a wide variety of applications
• Variable-speed extended trigger lets the user regulate • Two-speed drill (450/1,550 RPM)—low speed for higher
the proper RPM torque applications/high speed for steel drilling
• Nine-position clutch lets the user dial in the proper torque • Variable-speed switch—good featherability at low speed
• Includes (2) 14.4 V MicroLithium batteries for for driving screws and control
less downtime • Nine-position clutch delivers 8–50 in-lb of torque
• Rapid 70-minute charge time keeps the job moving • Lightweight drill—with battery only 3.2 lb
• Ergonomic cushion grip handle keeps the user working • 3/8ʺ keyless drill chuck—single-sleeve durable steel
comfortably all day chuck makes changing bits easy
• Easy-access Forward/Reverse button • Cushion grip handle—nonslip comfort for the operator,
• Includes tool, (2) batteries and a charger positive tool control allows the operator to work longer
with less fatigue
Colors Available • Small size to get in tight spots—under dash, firewall, etc.
• One-year full warranty and serviced by Snap-on
®
Service Centers
Red Green Hi-Viz • Built-in gauge displays the battery charge state
2 Batteries, 1 Charger: K2 GK2 HVK2 • Integrated LED light
Tool Only: DB GDB HVDB • Includes tool, (2) batteries and a charger
ADD SUFFIX TO STOCK NUMBER FOR SPECIAL COLORS
Colors Available

Red Green Hi-Viz
2 Batteries, 1 Charger: K2 GK2 HVK2
Tool Only: DB GDB HVDB
ADD SUFFIX TO STOCK NUMBER FOR SPECIAL COLORS
537
• Read safety precautions on pages W1 to W4
