Page 536 - 实耐宝完整US版1500

CORDLESS: 14.4-VOLT MICROLITHIUM PLATFORMS
TOOLS

POWER CTR717K2 CTR767K2

14.4 V Long-Reach Ratchets
Specifications CTR767K2** CTR717K2
Battery Type MicroLithium 2.5 Ah MicroLithium 2.5 Ah
Battery Voltage 14.4 14.4
Charge Time, minutes 70 70
Square Drive, inches (mm) 3/8 (10) 1/4 (6)
Torque Output, ft-lb (N•m) 40 (54) 35 (47)
Manual Torque, ft-lb (N•m) 158 (214) 46 (62)
Free Speed, RPM 275 350
Height with Battery, inches (mm) 15.75 (400) 13.7 (348)
Weight with Battery, lb (kg) 3.1 (1.4) 2.4 (1.1)
Warranty (battery) 1 Year 1 Year
Warranty (tool and charger) 1 Year 1 Year
Battery (qty) CTB8174 (2) CTB8174 (2)
Battery Charger CTC772A CTC772A
Tool Only CTR767DB CTR717DB
** – DE, ES, FR, IT, GB, NL, JP
CTR717K2 14.4 V 1/4ʺ Drive MicroLithium Cordless CTR767K2 14.4 V 3/8ʺ Drive MicroLithium Cordless
Long Reach Ratchet Kit Long Reach Ratchet Kit
• Powerful 35 ft-lb of torque output—the perfect tool for • 6ʺ-long extended neck for great accessibility
applications with fasteners sized 12 mm or smaller • 40 ft-lb of torque output
• High speed (350 RPM free speed) for quick fastener • 275 RPM free speed
removal and installation • Variable-speed trigger for greater control
• Dedicated 1/4ʺ drive ratchet platform with compact • Ratchet mechanism, ratchet head, and neck are strong
design for greater accessibility enough to handle 158-plus ft-lb of manual torque
• Variable-speed trigger for precise control • Includes tool, (2) batteries and a charger
• Built-in LED headlight illuminates the work area
• Includes tool, (2) batteries and a charger Colors Available
Colors Available
Red Green Hi-Viz
2 Batteries, 1 Charger: K2 GK2 HVK2
Tool Only: DB GDB HVDB
Red Green Hi-Viz
2 Batteries, 1 Charger: K2 GK2 HVK2 ADD SUFFIX TO STOCK NUMBER FOR SPECIAL COLORS
*1 Battery, 1 Charger: K1 GK1 HVK1
Tool Only: DB GDB HVDB
ADD SUFFIX TO STOCK NUMBER FOR SPECIAL COLORS
