P. 311
3/8" DRIVE CROWFOOT WRENCHES
BFCRM712A BFCR708A
®
®
Ratcheting, mm (Blue-Point ) Set BFCRM712A Ratcheting, inches (Blue-Point ) Contains:
Set
Contains:
BFCR708A
A C E A C E WRENCHES
8 BFCRM8A 17.8 6.5 49.3 • 5/16 BFCR10A 11/16 1/4 2 •
9 BFCRM9A 19.5 7.4 50.8 • 3/8 BFCR12A 27/32 5/16 2-1/8 •
10 BFCRM10A 21.5 8.0 53.8 • 7/16 BFCR14A 7/8 11/32 2-1/8 •
11 BFCRM11A 22.0 8.5 53.8 • 1/2 BFCR16A 31/32 13/32 2-1/4 •
12 BFCRM12A 23.5 9.0 57.2 • 9/16 BFCR18A 1-1/16 13/32 2-3/8 •
13 BFCRM13A 25.0 10.0 57.2 • 5/8 BFCR20A 1-3/16 7/16 2-5/8 •
14 BFCRM14A 27.0 10.0 60.3 • 11/16 BFCR22A 1-1/4 15/32 2-5/8 •
15 BFCRM15A 28.5 11.0 63.5 • 3/4 BFCR24A 1-7/16 1/2 2-7/8 •
16 BFCRM16A 30.5 11.0 66.7 • Set includes FXLBP10—10ʺ locking extension Set includes storage tray.
17 BFCRM17A 34.5 12.0 68.3 •
18 BFCRM18A 36.5 12.0 71.4 •
19 BFCRM19A 36.5 12.9 73.0 • Crowfoot Wrench Holder
A277 3/8ʺ Drive 8-3/4ʺ Crowfoot Wrench Holder
• Organizes and stores crowfoot wrenches A277
• 2 pc design snaps apart for access to
desired size
• 8-3/4ʺ long
1/2" DRIVE CROWFOOT WRENCHES
Open End, mm
Maximum Recommended
A C E F
Working Torque, in-lb
20 SCOM20 40.4 42.9 7.8 15.9 1,400
21 SCOM21 40.4 42.9 7.8 15.9 1,500
22 SCOM22 44.7 44.5 8.2 15.9 1,500
23 SCOM23 48.0 44.5 8.9 15.9 1,600
24 SCOM24 46.7 44.5 8.5 15.9 1,800
25 SCOM25 51.1 45.2 8.9 15.9 1,800
26 SCOM26 53.1 45.2 9.2 15.9 1,800
27 SCOM27 53.1 44.5 9.2 15.9 2,000
28 SCOM28 53.1 43.6 9.2 15.9 2,100
30 SCOM30 59.7 44.5 9.9 15.9 2,200 SCOM32
32 SCOM32 62.7 50.0 10.3 15.9 2,300
34 SCOM34 62.7 51.6 10.3 15.9 2,400
35 SCOM35 69.1 50.8 11.0 15.9 2,500
36 SCOM36 69.1 50.0 11.0 15.9 2,600
38 SCOM38 75.4 50.8 11.8 15.9 2,900
40 SCOM40 75.4 51.6 11.8 15.9 3,000
41 SCOM41 81.8 50.8 12.5 15.9 3,400
42 SCOM42 81.8 50.0 12.5 15.9 3,400
46 SCOM46 91.2 51.2 13.5 15.9 4,100
50 SCOM50A 100.8 53.8 14.6 16.1 —
Adjustable, inches/mm
ADCF8 3/8ʺ Drive Metric 0–29 mm Adjustable Crowfoot Wrench
• Metric and SAE scales
• Opening range from 0–1.14ʺ (0–29 mm)
• Lateral side nut is designed to work on difficult-to-access fasteners and minimizes
dirt accumulation
ADCF8
309
• Use only moderate force on crowfoot and flare nut wrenches
• Read safety precautions on pages W1 to W4
