POWER BIT SOCKETS

Hex/Standard (Power), inches, Industrial (1/2ʺ) 1/2”

A B
5/16 PSA10E 2-7/16 FA10E2
3/8 PSA12E 2-9/16 SA12E2
7/16 PSA14E 2-7/8 SA14E2
1/2 PSA16E 3-1/16 SA16E2
9/16 PSA18E 3-1/8 SA18E2
5/8 PSA20E 3-7/16 LAW120E2
PSA10E
3/4 PSA24E 4-1/16 LAW124E2 DRIVE

SURFACE DRIVE SOCKETS

Shallow, mm, Natural

A B C D E
15 DTM15A 22.3 22.9 21.3 38.1 10.7
DTM15A TOOLS

Deep, mm, Natural
Surface drive sockets will engage with a fastener while rotating on a power nut runner

A B C D E
13 DTSM13A 19.3 21.8 65.8 82.6 10.2
15 DTSM15A 22.3 21.8 65.8 82.6 10.7
DTSM13A

Deep, inches, Natural

A B C D E
1/2 DTS16A 3/4 29/32 2-19/32 3-1/4 13/32
9/16 DTS18A 13/16 29/32 2-19/32 3-1/4 13/32
DTS16A

Surface Drive (M-Series)
®
• Snap-on M-Series sockets offer a precise fit, optimum • Used in the industrial market for assembly line work
hardness, durability, ring-groove and pin hole for use • The lead-in chamfer and special design of these
on a variety of industrial fastening applications sockets will engage with a fastener while rotating on a
• M-Series sockets feature surface drive technology to power nut runner
ensure a long service life

A B C D E
11 M3111 16.6 23.6 19.1 38.1 8.1
13 M3113 22.0 23.6 19.1 38.1 9.7
15 M3115 23.6 23.6 21.3 38.1 12.4
15 M3215 23.6 23.6 40.4 57.2 12.4 M3115
18 M3118 28.4 28.4 21.3 38.1 11.2
