SPECIAL APPLICATION IMPACT SOCKETS

Crankshaft Bolt Socket 1/2”
S6324 1/2ʺ Drive 6-Point Metric 24 mm Crankshaft Bolt Impact Socket
®
®
®
• Used for removing and installing crankshaft bolts on Audi A4 , A6
and A8 vehicles
®
• Socket is 1/2ʺ drive 24 mm and overall length is 2ʺ which is critical
to the crank shaft bolt application
• Manufactured from special alloy steel
• Precision forged and heat treated for optimum strength and durability
• Flank Drive wrenching system grips fastener on the flanks/flats, increasing S6324
®
torque by 15–20% while preventing the fastener from rounding, and increasing
the life of the socket DRIVE

SIMDM360TW
DPSM16
Shallow/10-Point, mm Deep/Thin Wall, mm

A B D E A B C D E
16 DPSM16 24.6 24.6 38.1 11.9 36 SIMDM360TW 47.2 44.5 72.8 88.9 22.9 TOOLS
DPSM16 1/2ʺ Drive 10-Point Metric 16 mm Shallow SIMDM360TW 1/2ʺ Drive 6-Point Metric 36 mm Flank
®
Impact Socket Drive Deep Pinion Flange Nut Impact Socket
• Used for removing the rear lower control arm bolts • Thin-wall design provides extra room needed to remove
®
®
®
on 2001 and newer Honda Civic and Acura and install the differential pinion flange nut on the
®
®
®
RSX vehicles 2012 Chevy Camaro (USA) and Holden Commodore
• Forged from tough alloy steel (Australia) vehicles
• Heat treated to a lower hardness to add impact
resistance and ductility
POWER ACCESSORIES
Extensions/Lock Button, Industrial
Stock No. A B
PS2 5/8 2
PS3 5/8 3-1/2
PS5 5/8 5 PS10
PS10 5/8 10

Adaptors (Power)
Socket
Stock No. A B C D
Attachment
PA2A Pin Type 3/8 1/2 3/4 1-5/16
PA2A
Hex Shanks (Power)

Socket
Stock No. A B C D
Attachment
A3011A Pin Type 1/2 7/16 1-1/4 2-3/4 A3011A

243
• Read safety precautions on pages W1 to W4
