POWERED TORQUE TOOLS

TORQUE REACTION

A variety of reaction plates, manufactured in Steel or Aluminium for HandTorque®, EvoTorque®, EvoTorque® Battery Tool and PneuTorque®.
Norbar also offer a range of specific reactions for the Wind Energy Generation Industry.

11 SPLINED REACTION FOR HT/PTS/PTM-52 SERIES 11 SPLINED REACTION FOR HT/ET/EBT/PTS/PTM-119 SERIES
18646 Steel Cranked Reaction for 52 mm Steel Cranked Reaction for 119 mm (Max. 7,000 N·m)

11 SPLINED REACTION FOR HT/ET/EBT/PTS/PTM-72 & 80 SERIES
Steel Cranked Reaction for 72 mm and 80 mm

19293

19289

Aluminium Cranked Reaction for 119 mm (Max. 6,000 N·m)

Aluminium Cranked Reaction for 72 mm and 80 mm

18961

18494

11 SPLINED REACTION FOR HT/ET/EBT/PTS/PTM-92 SERIES
Steel Cranked Reaction for 92 mm

19291

Aluminium Cranked Reaction for 92 mm

18936

Part Number R1 R2 min R2 max
18646 59 mm 71 mm 131 mm
19289 76 mm 124 mm 167 mm
18494 68 mm 91 mm 165 mm
19291 70 mm 125 mm 175 mm
18936 87 mm 115 mm 205 mm
19293 90 mm 162 mm 210 mm
18961 118 mm 150 mm 199 mm
