ELECTRONIC SCREWDRIVER AND TORQUE WRENCHES

NORTRONIC® ELECTRONIC TORQUE WRENCHES
Calibration details

The NorTronic®, Norbar's electronic torque wrench,
sets the benchmark with its unique Torque Data
System (TDS) software and combination of accuracy,
wireless capability and angle measurement, in a
versatile, robust and easy to use package.
• Accurate and traceable torque and angle control
• Two full colour OLED displays positioned at 90° to each other for
visual indication both horizontally and vertically
• 3 models covering 5 - 330 N�m
• Extension bars can be made available to increase the operating
range of the tool up to 860 N·m, contact Norbar for more
information.
• IP44 protection against dust and water ingress
• One piece aluminium handle
• Extruded aluminium case
• Torque & Angle readings can be sent to TDS via the USB lead� For a 868
MHz or 915 MHz wireless connection, a wireless adaptor is required
for your PC. Each wireless adaptor can handle up to 8 wrenches.
NorTronic® Bluetooth® versions must be connected to TDS via USB lead
• Bluetooth® interface versions with plaintext protocol for easy
integration into user environments; set targets, get results, and stream
live torque and angle data using your own software and equipment on
phones, computers and tablets
• Ability to interface to ProSuite® process control software
• Calibration date of tool can be displayed via TDS or third party software
• ASCII mode allows for interfacing the tool to third party software
• When used with a HandTorque® gearbox the NorTronic® can directly
display, save and send the output Torque of the HandTorque®
• Ability to set a Torque, Angle and Final Torque Target
• Ability to produce and save Torque & Angle graphs (in real time) from a
USB connected tool
• Ability to have up to 15 linked or non-linked targets on the tool at any
one time
• Angle calibration in accordance with VDI/VDE 2648 Compatible with Norbar’s huge Unique Torque Data System
• UKAS accredited torque calibration in both clockwise and counter- range of spanner software enables data
clockwise direction end fittings management and archiving to a PC

NorTronic® Tool
Production NorTronic® Tool
NorTronic® DLL
Line Control Plugin Software
Software NorTronic® Tool
NorTronic® Tool

NorTronic® DLL (Dynamic Link Library) plugin enables NorTronic® 868 MHz
and 915 MHz version tools to be interfaced to a customer's existing production
line control software. DLL is not compatible with Bluetooth® versions.
Contact Norbar for more details.
