TORQUE WRENCH END FITTINGS

SPANNER END FITTINGS FOR 16 mm TORQUE HANDLES

On this page you will find our standard range of end fittings.
See below for explanation of part numbers. Other sizes available on request – including bespoke ETO solutions.
For other sizes, see page 43 & page 44.

2 OPEN ENDS METRIC 2 OPEN ENDS IMPERIAL 2 RING ENDS METRIC 2 RING ENDS IMPERIAL
29841 7 mm, 9 N·m* 29701 1 ∕ 4", 7 N·m* 29881 7 mm, 25 N·m* 29726 1 ∕ 4", 25 N·m*
29842 8 mm, 13 N·m* 29702 5 ∕ 16", 13 N·m* 29882 8 mm, 35 N·m* 29727 5 ∕ 16", 35 N·m*
29843 9 mm, 19 N·m* 29703 3 ∕ 8", 21 N·m* 29883 9 mm, 45 N·m* 29728 3 ∕ 8", 42 N·m*
29844 10 mm, 25 N·m* 29704 7 ∕ 16", 32 N·m* 29884 10 mm, 52 N·m* 29729 7 ∕ 16", 73 N·m*
29845 11 mm, 32 N·m* 29705 1 ∕ 2", 48 N·m* 29885 11 mm, 73 N·m* 29730 1 ∕ 2", 115 N·m*
29846 12 mm, 41 N·m* 29706 9 ∕ 16", 67 N·m* 29886 12 mm, 89 N·m* 29731 9 ∕ 16", 170 N·m*
29847 13 mm, 51 N·m* 29707 5 ∕ 8", 90 N·m* 29887 13 mm, 107 N·m* 29732 5 ∕ 8", 226 N·m*
29848 14 mm, 63 N·m* 29708 11 ∕ 16", 118 N·m* 29888 14 mm, 128 N·m* 29733 11 ∕ 16", 260 N·m*
29849 15 mm, 77 N·m* 29709 3 ∕ 4", 150 N·m* 29889 15 mm, 150 N·m* 29734 3 ∕ 4", 305 N·m*
29850 16 mm, 92 N·m* 29710 13 ∕ 16", 187 N·m* 29890 16 mm, 175 N·m* 29735 13 ∕ 16", 330 N·m*
29851 17 mm, 107 N·m* 29711 7 ∕ 8", 230 N·m* 29891 17 mm, 201 N·m* 29736 7 ∕ 8", 330 N·m*
29876 18 mm, 128 N·m* 29712 15 ∕ 16", 281 N·m* 29913 18 mm, 230 N·m* 29737 15 ∕ 16", 330 N·m*
29877 19 mm, 149 N·m* 29713 1", 330 N·m* 29914 19 mm, 261 N·m* 29738 1", 330 N·m*
29852 20 mm, 172 N·m* 29714 1 ∕ 16", 330 N·m* 29892 20 mm, 294 N·m* 29739 1 ∕ 16", 330 N·m*
1
1
29853 21 mm, 198 N·m* 29715 1 ∕ 8", 330 N·m* 29893 21 mm, 330 N·m*
1
29854 22 mm, 225 N·m* 29716 1 ∕ 16", 330 N·m* 29894 22 mm, 330 N·m*
3
29855 23 mm, 255 N·m* 29717 1 ∕ 4", 330 N·m* 29895 23 mm, 330 N·m*
1
29856 24 mm, 287 N·m* 29718 1 ∕ 16", 330 N·m* 29896 24 mm, 330 N·m*
5
29857 25 mm, 322 N·m* 29915 27 mm, 330 N·m*
29858 26 mm, 330 N·m*
29878 27 mm, 330 N·m*
29860 29 mm, 330 N·m*
29861 30 mm, 330 N·m*
29863 32 mm, 330 N·m*
297100 36 mm, 330 N·m*
2 FLARE ENDS METRIC
29921 7 mm, 7 N·m*
29922 8 mm, 6 N·m*
29923 9 mm, 5 N·m*
29924 10 mm, 26 N·m*
29926 12 mm, 13 N·m*
29927 13 mm, 34 N·m*
29928 14 mm, 24 N·m*
29929 15 mm, 18 N·m*
29930 16 mm, 66 N·m*
29931 17 mm, 56 N·m*
29953 18 mm, 45 N·m*
29954 19 mm, 80 N·m*
29932 20 mm, 60 N·m*
29933 21 mm, 43 N·m*
29934 22 mm, 172 N·m*
29935 23 mm, 153 N·m*
29936 24 mm, 118 N·m*
29955 27 mm, 76 N·m*

* Max torque values listed are proof torques quoted in BS 192:1982 &
BS 3555:1988 (tested on hardened hexagon test stud).
