ELECTRONIC SCREWDRIVER AND TORQUE WRENCHES

PROTRONIC® PLUS ELECTRONIC TORQUE WRENCHES

2

Large backlit LCD display

Model ProTronic Plus ProTronic Plus ProTronic Plus ProTronic Plus ProTronic Plus
100 ⅜" 100 ½" 200 ½" 340 ½" 800 ¾"
Part Number 130512 130513 130514 130515 130516
A 458 462 650 749 1,264
B 439 439 627 723 1,233
Dimensions C 344 344 533 629 1,138
(mm) ØD 38 46 46 52 63
E 34 45 45 45 55
F 21 29 29 29 32
Weight (kg) 1.15 1�30 1.65 1.85 4.95
A
B

Ø D

C

F
E

• Accuracy of ±2% when operating between 20% to 100% of tool capacity.
• Accuracy of ±4% when operating between 5% to 19% of tool capacity, except for ProTronic® Plus 9, 10 and 30 where the counter clockwise accuracy
between 5% to 19% will be 6%.
• Angle accuracy of ±1% of reading, ±1° @ Angular Velocity >10°/Sec < 180°/Sec, ±1° for test fixture
