DIN ISO 5745 38
>
>
> 38 11 200
38 71 200
70
38 91 200 / 38 95 200
45
38 15 200
2
40
3
38 21 200 38 31 200
40°
38 41 190 38 71 200
70°
38 91 200
45°
L3 W3 T1 W4 T2
货号 mm mm mm mm mm mm g
38 11 200 200 73.0 17.5 9.5 3.0 2.5 179
38 15 200 200 73.0 17.5 9.5 3.0 2.5 209
38 21 200 200 40° 73.0 17.5 9.5 3.0 2.5 175
38 25 200 200 40° 73.0 17.5 9.5 3.0 2.5 209
38 31 200 200 73.0 17.5 9.5 3.0 2.5 176
38 35 200 200 73.0 17.5 9.5 3.0 2.5 205
38 41 190 190 50.0 18.0 8.0 2.0 8.0 139
38 45 190 190 50.0 18.0 8.0 2.0 8.0 171
38 71 200 200 70° 73.0 17.5 9.5 3.0 2.0 174
38 91 200 200 45° 73.0 17.5 9.5 2.5 177
38 95 200 200 45° 73.0 17.5 9.5 2.5 207
