UNDERCAR SERIES

Hydraulic HGV Ball Joint Separator & Set

9HBE81
• Use for separating ball joint for heavy goods vehicles
• Design for operating manually or by 12 tons hydraulic ram 3
• Strengthen fork and lever for greater force to be applied PC.

Kg 7.00 1 / 2

capacity
Jaw opening 70mm
Jaw width 36mm

9HBE083
• Use for separating ball joint for heavy goods vehicles
• Design for operating manually or by 12 tons hydraulic ram 5
• Interchangeable jaws width : 30 / 34 / 40mm
PC.
Kg 8.50 1 / 2

Jaw Opening size : 30, 34,
40 mm

Track Rod End Remover Multi-Purpose Inner
& Installer Tie Rod Tool

9BE51 9BE52 9BE62 9BE63 1/2"

• Removes and replaces the axial joint • Use for replace inner tie rod ends without removing
• Hex part on the end of tool : works with 27 mm wrench the rack and pinion
or 1/2" DR. ratchet • Internal serrated design to make grip tight
• Use with ratchets and extensions by 1/2" DR.
• Suitable for most vehicles & trucks

Ø

L

L
KT NO. inch mm Ø Capacity g L
mm
9BE51 15-3/4 400 28~35 1635 1 / 10
9BE52 15-3/4 400 35~45 2140 1 / 10
L
KT NO. inch mm Ø Capacity g
mm
9BE62 3-1/4 81.50 33~42 370 24
9BE63 3-7/16 87.56 42~50 422 24
566
