ENGINE SERIES

BMW
Diesel Engine Timing Locking Set

9AT2107E

• The set includes camshaft alignment tool, flywheel locking
tool, crankshaft pulley turning tool, and also high pressure
pump sprocket removal tool
• Suitable for BMW N47 / N47S / N57 2.0 and 3.0 twin
camshaft diesel chain drive engine
• Use to set & lock the camshaft and crankshaft when 8
adjusting valve timing on engine correctly D CHAIN PC.

g 1730 1 / 10

1 Series
116d/118d/120d/123d
E81/82/87/88 (07-12)
3 Series
316d/318d/320d/325d/330d/330xd
E90/91/92/93 (07-12)
5 Series
520d E60/61 (07-10)
525d/530d/535d F10/11 (10-12)
530d GT/535d GT F07 (09-12)
MODEL: CONTENTS :
7 Series • A – camshaft Alignment Tool
730d/730Ld/740d/740d xDrive • B – flywheel Locking Tool
F01/02/04 (08-12) • C – crankshaft Turning Tool
X Series • D/F – high pressure pump sprocket removal tool
X1 sDrive 18d/20d E84 (09-12) • E – tensioner Locking Pin
X1 xDrive 18d/20d/23d E84 (09-12)
X3 20d E83 (07-10)
X3 xDrive 1.8d/30d E83 (08-12)
X5 30d/xDrive 40d E70 (10-12)
X6 xDrive 30d/40d E71/72 (10-12)

N47 / N47S
D20A
D20B
D20T0
D20O0
ENGINE
CODE: D20UO
N57
D30U0
D30O0
D30O1
D30T0

518
