Digital Clamp Meter

9DM2351
• Max clamp size : Ø 30mm
• Unit & function indication, maximum reading value 1999 digits
• Negative polarity indicator (no indication is given for positive polarity)
• Auto power off selection approx. 15 minutes
• Low power consumption
• AAA battery x 2 PC. (Battery not included)
• CE approval IEC 61010-1, IEC 61010-2-032
CAT.III 600V Pollution Degree 2
• Attachable test leads, easy operation

Specification
AC Ampere (0.1A - 1A) 200A / 600A
AC Voltages (0.001V - 1V) 2V / 20V / 200V / 600V

DC Voltages (0.1mV - 1V) 200mV / 2V / 20V / 200V / 600V

200Ω / 2kΩ / 20kΩ / 200kΩ /
Resistance (0.1Ω - 0.01MΩ)
2MΩ / 20MΩ
Continuity check Yes
Diode test Yes
Low battery indicator Yes

LCD Display 3 1/2 digits 1999 counts
Sampling rate 3 times / Sec.
Overload indicator OL
Size (mm)
KT NO. L x W x H g
9DM2351 189 x 71 x 37 354 5 / 40

AC Non-contact Voltage Tester

6CB31

• Voltage ranges : 80 to 1000V AC.(50~60Hz)
• Application :
AC voltage in outlets, lighting, circuit breakers,
wires and cables etc..
• Adjustable sensitivity voltage detection
• Visible LED light voltage indicator in tip
(Green light is high gear, red light is low gear)
• AAA battery x 2 PC. (Battery not included)
• Standard category : Overall size (mm)
EN 61000-6-3 / EN 61000-6-1 CAT III KT NO. L x W x H g
6CB31 160 x 20 x 24 72 10 / 100
Measurement level

The input voltage should not exceed the maximum value.
Measurement
level Description Example
Measurement directly The secondary of
CAT.I connected to the power the transformer
Inside wire supply circuit board measured
Distribution CAT.III CAT.II Measurement board
panel CAT.II directly connected to the Equipment,
Outside wire low voltage devices portable devices
CAT.IV CAT.I CAT.III Equipment within Distribution panels,
the building circuit breakers
Outlet
Fixed equipment ... etc. Sources of all low Overhead lines,
Equipment CAT.IV voltage installations cable facilities
