HAND SOCKET & ACCESSORIES
Deep Socket KT No. & D1
4235M 4235S 1/2" 4245M EXTENDED 1/2"
LENGTH
• Metric-DIN 3124, ISO 2725-1 • DIN 3120
• ANSI / ASME B107.1 1/2"
D1 D2
D1 D2
l L l L
ℓ
D2
L
D1
KT NO. mm mm mm mm mm g
9.0
D1
D2
L
ℓ
KT NO. mm mm mm mm mm g 424508M 8 13.2 21.7 10.0 90 104 6 / 120
106
9
90
424509M
14.0
6 / 120
21.7
423508M 8 13.2 22.0 16 77 90 6 / 120 424510M 10 15.2 23.7 11.0 90 130 6 / 120
423509M 9 14.0 22.0 16 77 81 6 / 120 424512M 12 17.7 23.7 13.0 90 152 6 / 120
423510M 10 15.2 23.7 24 77 102 6 / 120 424513M 13 18.7 23.7 14.0 90 151 6 / 120
423511M 11 16.3 23.7 24 77 103 6 / 120 424514M 14 20.2 23.7 15.0 90 159 6 / 120
423512M 12 17.7 23.7 24 77 113 6 / 120
423513M 13 18.7 23.7 24 77 119 6 / 120
423514M 14 20.2 23.7 35 77 121 6 / 120
423515M 15 21.3 23.7 35 77 126 6 / 120 4255M EXTENDED 1/2"
423516M 16 22.6 23.7 35 77 130 6 / 96 LENGTH
423517M 17 23.7 23.2 35 77 127 6 / 96 • DIN 3120
423518M 18 25.5 23.2 35 77 149 6 / 96
423519M 19 25.7 23.2 35 77 133 6 / 96
423520M 20 27.7 24.0 35 77 158 6 / 96
423521M 21 27.7 25.0 35 77 155 6 / 96 D1 D2
423522M 22 29.8 26.0 35 77 185 6 / 96 l L
423523M 23 31.8 27.5 35 77 218 5 / 60
423524M 24 31.8 28.5 35 77 211 5 / 60 D1 D2 ℓ L g
423525M 25 33.8 29.5 35 77 251 5 / 60 KT NO. mm mm mm mm mm
423526M 26 35.8 30.5 35 77 236 5 / 60 425508M 8 13.2 21.7 9 120 127 6 / 96
423527M 27 35.8 31.5 34 77 295 5 / 60 425509M 9 14.0 21.7 10 120 134 6 / 96
423528M 28 37.8 32.5 34 77 281 5 / 50 425510M 10 15.2 23.7 11 120 160 6 / 96
423529M 29 37.8 33.5 34 77 292 5 / 50 425512M 12 17.7 23.7 13 120 195 6 / 96
423530M 30 39.8 34.5 34 77 301 5 / 50 425513M 13 18.7 23.7 14 120 201 6 / 96
423532M 32 41.8 36.0 34 77 330 5 / 50 425514M 14 20.2 23.7 15 120 202 6 / 96
423533M 33 43.8 38.5 35 77 373 5 / 50
423534M 34 44.8 38.5 35 77 478 5 / 50
423536M 36 46.8 40.5 36 77 478 2 / 40
423538M 38 49.0 40.5 38 77 504 2 / 40
423541M 41 53.0 40.5 40 77 521 2 / 24
Square Socket
ℓ
D2
L
D1
KT NO. inch mm mm mm mm g 4014M 1/2"
423510S 5/16 13.2 22.0 16 77 90 6 / 120
423512S 3/8 14.7 22.0 16 77 84 6 / 120 • DIN 3120
423514S 7/16 16.3 23.7 24 77 104 6 / 120
423516S 1/2 18.7 23.7 24 77 116 6 / 120 D
423518S 9/16 20.2 23.7 35 77 123 6 / 120
423520S 5/8 22.6 23.7 35 77 130 6 / 96 l L
423522S 11/16 23.7 23.2 35 77 124 6 / 96
423524S 3/4 25.7 23.2 35 77 131 6 / 96
423526S 13/16 27.7 25.0 35 77 157 6 / 96 KT NO. D ℓ L g
423528S 7/8 29.8 26.0 35 77 181 6 / 96 mm inch mm mm mm
423530S 15/16 31.8 28.5 35 77 218 5 / 60 401408M RB8.0 23.5 13.5 35 54 10 / 200
423532S 1 33.8 29.5 35 77 223 5 / 60 401409M RB9.5 3/8 23.5 13.5 35 58 10 / 200
423534S 1-1/16 36.6 31.5 34 77 266 5 / 60 401410M RB10.0 23.5 13.5 35 57 10 / 200
423536S 1-1/8 37.8 32.5 34 77 262 5 / 50 401411M RB10.5 23.5 13.5 35 58 10 / 200
423538S 1-3/16 39.8 34.5 34 77 296 5 / 50 401412M RB12.0 23.5 13.5 35 62 10 / 200
423540S 1-1/4 41.8 36.0 34 77 327 5 / 50 401413M RB12.7 1/2 23.5 13.5 35 64 10 / 200
423542S 1-5/16 44.0 38.5 35 77 430 5 / 50 401414M RB13.5 23.5 13.5 35 67 10 / 200
423544S 1-3/8 46.0 38.5 35 77 452 2 / 40 401419M RB19.0 25.0 15.5 40 108 10 / 160
423546S 1-7/16 47.5 40.5 36 77 485 2 / 40
423548S 1-1/2 49.0 40.5 38 77 507 2 / 40
