Specialty Tools

Body and Interior Equipment – Commercial vehicle

Steering wheel

1776 Pitman arm puller ∙ 2-arm 2223 LG Bit

Made in Germany Q • Long design Q NF
1
• For ball bearings, toothed wheels, pinions, • Hexagon drive similar to ISO 1173 C6.3 ( ⁄4″)
pitman arms and similar G
• The clamp clip is used for pressing the
puller jaws on the parts to be extracted
• Surface: galvanised

1 K r 4 F

• Round blade
1 U a Spindle 4 • Suitable for all MERCEDES-BENZ passenger cars
model year → 2011 with bolted air bag unit
1776- 85 90 85 M 18 x 1.5 x 130 mm 135943 • For removal and installation of the airbag unit e.g. MERCEDES-BENZ,
1776-100 90 100 M 18 x 1.5 x 130 mm 135950 VW, AUDI, OPEL/VAUXHALL, PORSCHE (inside h screws T30)
1
1776-140 150 140 G ⁄2″ x 175 mm 135967 2223 Lg-T 30 70 5.52 015092
Commercial vehicle D

Engine
Cylinder head

2850 h impact socket
R
Made in Germany J e9
• Operation of cylinder head bolts
• Reinforced design
• Long design
• With borehole for locking pin or safety spring and grove for O-ring
• Surface: phosphatized, oiled
• DIN 3124, ISO 2725-2
C

1 K G H r c 4

• MAN commercial vehicles F 2000, F 90, F 8 and
MAN buses with D 25 and D 28 engines
2850-E 20 110 25 44 18.49 15 079681
• MAN commercial vehicles with Common Rail Engine (D20)
2850-E 24 110 30 44 22.16 17.5 146758
O
Fuel System / Fuel Injection

2168 Fuel filter wrench

Made in Germany 8
• Easy operation with introduced square 12.5 mm ( ⁄2 inch)
1
• Application: Operation of fuel filter housing on A
construction and agricultural machinery
• For e.g.: CLAAS Torion, LIEBHERR wheel loaders and wheel loaders with
Euro 6 emission standard and LIEBHERR, JOHN DEERE engines
• Harvester 1070G, 1170G ∙ Forwarder 1110G, 1210G, 1510G ∙ Caterpillar-track
timber crane 2154G, 2154 G ∙ Log loader 2156G, 2156G LC ∙ Timber crane,
hitch-mounted 337E, 437E ∙ Wheel loader 524K, 524K-II, 524L, 544K, 544L ∙
Field sprayer, self-propelled R403, R4040L, R4050L ∙ Tractors 6M, 6R series ∙
Tractors 7R series ∙ Combine T series ∙ Combine W series ∙ Bulldozer 700K ∙
Excavator 210G LC Deere ∙ Sprayer Mazzotti MAF HP ∙ Hagie STS 10, STS 12
U

1 4
2168-1 223251
