Specialty Tools Specialty Tools

Chassis – Wheel Bearing / Wheel Hub Chassis – Wheel Bearing / Wheel Hub

4932 Threaded spindle 4932 Adapter for hollow piston cylinder 4932-17

Made in Germany C C C
• Threaded spindle with steel cable TR 20 (for
hollow piston cylinder 4932-17 and nut 4930-2)
G 1 4
Adapter for Klann hollow piston cylinder KL-0040-2500
• Coupler thread for HAZET housings 4930-721 ∙ -821 ∙ -851 as
well as pressure plates 4934-10 ∙ -8510 ∙ -7801
• Coupler thread: M 27 x 2
• Outside x: 80 mm
1 K 4 4932-M 27 x 2 160037
Adapter for hollow piston cylinder HAZET 4932-17
F 4932-TR 20 546 159765 • Adapter with coupler thread for operating tools made by Klann
• Coupler thread: M 42 x 2
4934 Pressure plate • Outside x: 80 mm
• Enables working with the operating tool made by Klann for wheel bearing
and silent block tools by using the HAZET hollow piston cylinder 4932-17
Made in Germany C 4932-M 42 x 2 183432
• Together with hollow piston cylinder 4932-17
• Attaching the protective cover device 4934-7
• Thread inside: M 27 x 2 4932 Air-hydraulic pump
Made in Germany C/
D • With manometer and 1.8 metre hydraulic hose with coupling
• Working pressure: maximum 700 bar
• Air inlet thread: 12.91 mm ( ⁄4") 3
1
1 t 4 • Hydraulic connection: 16.41 mm ( ⁄8") – 18 NPTF
• Big pedal: pump, hold, release
• Tank made of sheet steel
• Hydraulic pressure plate for 4934-2572/12, -2562/6, -2566/6 using 4932-17 • Filling capacity: 1500 cm³
4934-10 122 159932 • Useful capacity: 1000 cm³
• Hydraulic pressure plate for 4934-2585/12 when using 4932-17 • Dimensions: 260 x 140 x 186 mm
R 4934-8510 137 159628

4930 Housing
Made in Germany C
• Thread inside: M 27 x 2 1 4
4932 N-110 187393

C 4931 Inner bearing extractor set

Made in Germany C
1 4 • For inner bearing rings that rest against the wheel hub

• Application: Extracting the inner bearing rings on the
• Housing x 72 mm for product group 4930 using wheel hub when removing the wheel bearing
4932-17 with 4932-TR 20 and 4930-2 • Increased torque allows firm collet chuck tightening.
4930-721 159598 Preventing from slipping-off the bearing ring
O • Housing x 82 mm for product group 4930 using 159604 • Also suitable for types with ABS housing (in particular
for permanently attached versions)
4932-17 with 4932-TR 20 and 4930-2
• For AUDI ∙ BMW ∙ FORD ∙ MERCEDES-BENZ ∙
4930-821
PEUGEOT ∙ RENAULT ∙ TOYOTA ∙ VW
• Housing x 85 mm for product group 4930 when • Spindle with motion screw thread allows high removal forces
using 4932-17 with 4932-TR 20 and 4930-2
4930-851 159611 • Torque arm for holding entire assembly in machinist’s vice for optimal work
• 4 chucks (40 to 45 mm / 45 to 50 mm / 50 to 55 mm / 55 to
61 mm) covering all diameters from 40 to 61 mm
4932 Adapter for hollow piston cylinder 4932-17 • Detailed, illustrated operating instructions
• Plastic box
• Soft foam insert
Made in Germany
A C

1 4

U Adapter for spindles with thread M 20
• Increases compatibility of HAZET hollow piston cylinder
with further threaded spindles and specialty tools
• Also suitable for tools of other manufacturers 1 è 4
4932-M 20 165681
B 4931-1/8 8 155538
