Page 438 - HAZET英文2021

Specialty Tools

Chassis – Wheel Bearing / Wheel Hub

4930 Spacer plate 4930 Centring sleeve

Made in Germany C C C
1 4
• For bearing inner x 39 / 41 mm G
4930-39 x 41 081028
• For bearing inner x 43 / 45 mm
4930-43 x 45 097739
1 4
4930-3 081158 4930 Thrust washer
4930-4 081141 Made in Germany
4930-5 082834 C
F

4930 Reduction ring
Made in Germany C

1 4

• For bearing outer x 62–64 mm D
4930-62 080854
1 4 • For bearing outer x 64–66 mm 080939
4930-64
• For VW Polo C and PEUGEOT 106 • For bearing outer x 66–68 mm
• Together with housing 4930-721 4930-66 080946
4930-6 083633 • For bearing outer x 68–70 mm
• In conjunction with housing 4930-851 4930-68 080953
4930-7 083640 • For bearing outer x 72–74 mm
• Inside x 45 mm in conjunction with 4930-8245 4930-72 080960 R
4930-8 097890 • For bearing outer x 74–76 mm
4930-74 080977
4930 Centring disc • For bearing outer x 80–82 mm
4930-80 081004
Made in Germany C • For bearing outer x 82–84 mm
• Installing the wheel bearing on AUDI A4 ∙ A6 4930-82 080991
• Together with 4930-8 inner x 45 mm
• For bearing outer x 82 mm
4930-8245 097746 C
• For bearing outer x 84–85 mm
4930-84 081448
1 4 4932 Hollow piston cylinder

4930-9 121465
Made in Germany C
• Compact hydraulic cylinder with a capacity of 17 tonnes
4930 Centring sleeve O
• Working pressure: maximum 700 bar
• Convenient spring reset
Made in Germany C • For threaded spindle 4932-TR20 and nut 4930-2
• Traction side: M 27 x 2, alternatively M 42 x 2, using the optional adapter
• Pressure side: 2- ⁄4" – 14 UNS
1
inside thread: TR 20, alternatively M20, using the optional adapter
• Stroke: 45 mm
• Outside x: 80 mm
• Cylinder height – retracted: 206 mm / extended: 251 mm
• Including coupling, protective cap and adapter 4932-M 20 A
• Weight: 5.5 kg

1 4
• For bearing inner x 34 / 40 mm
4930-34 x 40 081042
• For bearing inner x 35 / 40 mm
4930-35 x 40 081066
• For bearing inner x 35 / 42 mm 4934-7 U
4930-35 x 42 081035
• For bearing inner x 37 / 45 mm 1 4
4930-37 x 45 081073
B 4932-17 159741

Components and spare parts from page 482 to 490 Valid until December 31, 2021 437
