Specialty Tools

Chassis – Spring Vices / Shock Absorbers

4910 Shock absorber tool set 4910 Counterholder for piston rod

Made in Germany C/ NbYc8 Made in Germany C b8
• Application: Repair work at • Application: Repair work at the strut
the strut e.g. shock absorber, strut mounting, coil spring e.g. shock absorber, strut mounting, coil spring
• Counterholder for piston rod when removing and installing the spring strut • Drive with ball race
• Caution: Follow vehicle manufacturer’s specifications concerning torque values G
• Application e.g. with torque wrench, e.g. HAZET 6291–1 CT together with insert
box-end wrench 6630 d-21
Application of an impact wrench may damage the
thrust bearing and the piston rod
• Shock absorber tool set, contents: 1
4910-1 S K 4
4910-6 ∙ 7 ∙ 8
4910-16 ∙ 17 ∙ 18 ∙ 19 ∙ 21 ∙ 22 ∙ 24 • On e.g. BMW
4910-58 ∙ 68 1 Series F20 ∙ F21 model year 2011 →
2 Series F22 ∙ F23 ∙ F45 ∙ F46 model year 2013 →
3 Series F30 ∙ F31 ∙ F34 ∙ F35 model year 2011 →
4 Series F32 ∙ F33 ∙ F36 model year 2013 → F
X1 F48 ∙ F49 model year 2015
4910-5 5 122.5 214549
4910-6 6 122.5 062089
4910-7 7 122.5 062096
4910-8 8 122.5 062102
Made in Germany C Y8
• Application: Repair work at the strut
e.g. shock absorber, strut mounting, coil spring D
• Drive with ball race

1 S K 4
1 L x W x H è 4 4910-58 Y 5 x 8 122.5 062119
mm
4910/13 355 x 235 x 65 13 061495 4910-68 Y 6 x 8 122.5 062126 R
• For PORSCHE Cayenne S ∙ VW Touareg ∙ Touran ∙ Sharan
4910-71 Y 7.1 x 9.6 122.5 091195
4910 Reversible ratchet
Made in Germany C N8
Made in Germany C/ • Application: Repair work at the strut
• Application: Repair work at the strut e.g. e.g. shock absorber, strut mounting, coil spring
shock absorber, strut mounting, coil spring • Drive with ball race
• Reversible ratchet • For OPEL/VAUXHALL Astra H ∙ MERCEDES-BENZ C-Class
C
• Output 12-point 21 mm (204) ∙ E-Class (212) ∙ E-Class Coupé (207)

1 K 4 1 K 4

4910-1 275 062133 4910-T 50 122.5 120598
O
4910 Socket ∙ 6-point
Made in Germany C c
• Application: Repair work at the strut e.g.
shock absorber, strut mounting, coil spring
• Retaining the piston rod when removing and installing the spring strut
• Caution: Follow vehicle manufacturer’s specifications concerning torque values
• Drive Ä 21 mm
A

1 S K 4

4910-16 16 82 062010
4910-17 17 82 062027
4910-18 18 82 062034 U
4910-19 19 82 062041
4910-21 21 82 062058
4910-22 22 82 062065
4910-24 24 82 062072
