Specialty Tools Specialty Tools

Engine – Exhaust System / Lambda Probe Gearbox

Exhaust System / Lambda Probe

4684 Exhaust equipment tool 4682 Chain tube cutter

• Hook 40 mm, bent 9° E • Easy adjustment due to T-screw during cutting process E/
G • Application: Installation and removal of rubber retainers of the • Application: Cutting pipes made of galvanized or stainless (V2A) steel,
copper, PVC and aluminium up to a wall thickness of 6 mm and 115 mm x
exhaust systems e.g. for FORD Fiesta, Orion, Escort, BMW etc.
• Plastic T-handle • 15 cutting wheels made of alloyed steel
• Surface: chrome-plated • Surface: nickel-plated

F

1 K t 4
1 K 4 4682-1 315 20 – 115 149384

4684-1 209 022199 • Spare chain for 4682-1
D Made in Germany E 4682-03 – – 149421

• Hook 17 mm, half-round, 20° offset 850 LG-GE h socket
• Application: Installing and removing rubber retainers of the exhaust systems
e.g. for VW ∙ AUDI ∙ MERCEDES-BENZ ∙ OPEL/VAUXHALL, Japanese cars etc. Made in Germany e6
• Plastic T-handle • Application: Operation of the oil pan screw connection in the engine
• Surface: chrome-plated and automatic gearbox.
Removal of the EGR radiator, EGR valve, valve cover etc. in MERCEDES-BENZ
etc. in the OM 651 engine
Removal of the gearbox holder no longer required, time saving: approx.
R 20 minutes
Much better accessibility to the screw connection on EGR valve and
radiator enables further time saving of approx. 15 minutes
• Use and extension permanently connected
• With hinge – for working in areas with restricted access
and for getting around obstructive edges
• Surface: chrome-plated, polished
• DIN 3124, ISO 2725-1

1 K 4
C 4684-2 209 022205

4682 Chain tube cutter

• Easy adjustment due to T-screw during cutting process E/
• Application: Cutting e.g. exhaust pipes especially made from
V2A steel up to a wall thickness of 2.5 mm and 75 mm x
O • Extended cutting diameters are achieved by using 1 K G H r 4
extension chain HAZET 4682-01
• Little effort, fixed with Grip technique
• Surface: nickel-plated 850 Lg-GE 10 150 12 13.5 9.42 223572

A

1 K t 4
4682 255 15 – 75 022168
U • Spare chain for 4682 – – 022175
4682-01
• Replacement set ∙ 9 pieces for repairing the cutting chain 4682-01
For 4682
4682-01/9 – – 057214
408 Valid until December 31, 2021 Components and spare parts from page 482 to 490
