Specialty Tools

Engine – Diagnostics

4800 Universal adapter 4810 C Optical tester
C C
KG GK
1 4
• Especially for Japanese vehicles x 18 – 24 mm G
• All current MAZDA models
• V-clamp fastening
4800-31 078196

4795 Engine leakage tester
1 4
Made in Germany KJ
• Easy application, immediate test result 4810 C 186402
• Application: For the diagnosis of engine defects, F
e.g. on inlet and exhaust valves, pistons/piston rings 4800 Cylinder head leakage tester
and cylinder head/cylinder head gasket
Made in Germany KG
• For radiator adapter HAZET 4800
• Application: Safe detection of cylinder
head damage and leakages between
the combustion chamber and the cooling
system on water-cooled combustion D
engines gas, diesel, petrol
• Reaction fluid included

1 4
4795-1 083770
• Adapter for motorcycles
• Thread M12 x 1.25 (outside thread) R
4795-11 083787
• Adapter for motorcycles and diesel engines 1 4
• Thread M10 x 1 (outside thread)
4795-12 083794 4800-41 058891
• Adapter for diesel engines • Reaction fluid (250 ml)
• Thread M24 x 2 (outside thread) For HAZET cylinder head leakage tester 4800-41
4795-13 083800 4800-041 108985
• Adapter for VW diesel engines including 4795-11
• Pin x 7 mm 4793 Cylinder head tightness tester C
4795-14 083817
• Adapter for multi-valve engines Made in Germany
Thread M 14 x 1.25 KG/
• Length 165 mm • Application: Detecting cylinder head gasket defects,
leaks between the combustion chamber and the cooling system
4795-15 104345 • For water-cooled combustion engines (gas, diesel and petrol)
• Adapter for multi-valve engines • Sheet metal box (HAZET-blue)
• Spark plug thread M12 x 1.25 • 2-component soft foam insert
(14 mm spark plugs)
4795-16 215140 O

4810 C Optical tester

Made in Germany GK
• (Refractometer) – Also suitable for G12++, G13, G48, G64, AdBlue
• Application: For testing the anti-freeze concentration in the cooling water,
also suitable for cooling fluids G11, G12++, G12 EVO, G13, G40, G48 and G64
For testing the quality of AdBlue solution A
For testing the battery acid concentration (state of battery charge)
• Optical tester (refractometer) with integrated lighting (LED) in the lid
• Incl. pipette and operating instructions
Description of scales:
A – state of charge
B – AdBlue concentration 1 L x W x H è 4
C – anti-freeze concentration mm
D – screenwash anti-freeze concentration 4793/3 320 x 128 x 58 3 076192
5 – Light/ dark line for reading the scale
• Tester
4793-1 – – 076185 U
• Reaction fluid (250 ml)
4793-2 – – 076208
• Flushing fluid (250 ml) for cleaning the tester 4793-1
B 4793-3 – – 076215

Components and spare parts from page 482 to 490 Valid until December 31, 2021 407
