Workshop Tools · Safety at Work Workshop Tools · Safety at Work

Lubrication technology Lubrication technology

2162 High performance suction gun 2162 Hand-operated dosing pump

• Unneeded material can be easily sucked back • The double scale enables precise dosing of various liquids
• Flexible plastic hose outlet
• Housing material: galvanised steel • Coupler thread (hose/pipe) on the pump bottom: M15 x 1.5
• Housing material: PVC (transparent)
• Hose inside x: 10 mm
• Hose outside x: 16 mm
• NBR seals
• Unneeded material can be easily sucked back
• Incl. flexible, transparent plastic hose fibre-reinforced
• Including curved 120° aluminium application tube x 10 mm
• Absorbent and smooth
• Hose length 600 mm plus application tube
• Maximum transport volume 4 l/min
• Length without house 545 mm

2162-6
1 ] 4

• Filling capacity: 500 ml
• Inside diameter of the hose: 9,5 mm
• Outside diameter of the hose: 12.5 mm
• NBR seals
• For engine oils with a viscosity of 30 to 68
• Not suitable for acidic (erosive) liquids
2162-4 0.5 174850
• Metal outlet also included
• Filling capacity: 1000 ml
• Inside diameter of the hose: 9.5 mm
• Outside diameter of the hose: 12.5 mm
• NBR seals
• For engine oils with a viscosity of 30 to 68
• Not suitable for acidic (erosive) liquids 1 ] 4
• Coupler thread (hose/pipe) on the pump bottom: 12.7 mm ( ⁄4″) PT x 19
1
2162-6 1 174454 2162-8 0.7 213337

2162 Manual decanting / filling pump Hand pump with telescopic
2163 suction tube 16 l/min.
Made in Germany
• 600 ml pump volume enables fast transfer pumping and filling of fluids Made in Germany
between different tanks
• Suitable for drums from 50 to 200 l
• Telescopic suction tube made of metal,
• Application: Filling and decanting liquids extendable from 450 to 860 mm
• Base plate and double connection for hoses with 10/15 mm inside x • Base component made of galvanised steel
• 1 suction hose, length: 3 m • R 2" and R ⁄2" drum adapters
11
• 1 pressure hose, length: 3 m • Removable, bent outlet made of metal
• On e.g. MERCEDES-BENZ Citaro Euro 6 together with coolant • Flow rate: approx. 0.35 l / stroke
pipe 2 x A.311.500.09.91 and coupling muff A.001.553.19.26 and
coupler plug A.001.553.20.26 • Weight: 2.2 kg
• Transmission or engine oils can be filled quickly, Caution: Not suitable for gasoline extraction
bubble-free and cleanly using the pump
• Fluids to be transferred, e.g.
– Ad Blue
– Cooling fluids
– Windscreen frost protection
– Oil
– Water

1 4 1 4
2162-7 207756 2163-1 172771
370 Valid until December 31, 2021 Components and spare parts from page 482 to 490
