1670-...
ENGINEER'S HAMMER, ENGLISH PATTERN

³ drop forged hammer head
³ inductive hardened and coated
³ face and peen polished
³ ash handle
³ mechanically fixed with a ring steel wedge
and epoxide resin
³ ELORA-high grade tool steel C45 / 1.0503

Code Number lb. l/mm Pieces Weight/g
n T U V
1670100237000 1670-1/2 1/2 295 2 310
1670100287000 1670-3/4 3/4 315 2 465
1670100347000 1670-1 1 335 2 555
1670100387000 1670-1.1/2 1.1/2 365 2 825
1670100497000 1670-2 2 375 2 1025

1670ST-... 1670KL-...
HANDLE FOR ENGINEER'S HAMMER WEDGE FOR ENGINEER'S HAMMER
³ for ELORA-No. 1670-..., English pattern ³ for ELORA-No. 1670-..., English pattern
³ ash handle according to DIN 5111

Code Number lb. l/mm Pieces Weight/g Code Number lb. Ø Pieces Weight/g
n T U V n U V
1670100238000 1670ST-1/2 1/2 295 6 81 1670400230000 1670KL-1/2 1/2 8 6 2
1670100288000 1670ST-3/4 3/4 315 6 98 1670400280000 1670KL-3/4 3/4 10 6 3
1670100348000 1670ST-1 1 335 6 105 1670400340000 1670KL-1 1 12 6 6
1670100388000 1670ST-1.1/2 1.1/2 365 2 132 1670400380000 1670KL-1.1/2 1.1/2 13 6 7
1670100498000 1670ST-2 2 375 2 150 1670400490000 1670KL-2 2 15 6 8

1672-...
CLUB HAMMER, GERMAN PATTERN
³ drop forged hammer head with safety collar
³ inductive hardened and coated
³ faces polished
³ ash handle with shaft protection bush made of nylon 09
³ mechanically fixed with a steel ring wedge and epoxide resin
³ ELORA-high grade tool steel C45 / 1.0503
³ hammer head according to DIN 6475,
handle according to DIN 5135

Code Number g l/mm Pieces Weight/g
n Ø U V
1672010007000 1672-1000 1000 g 260 2 1180
1672012507000 1672-1250 1250 g 260 2 1430
1672015007000 1672-1500 1500 g 280 2 1690
1672020007000 1672-2000 2000 g 300 2 2200
You will find the matching OMS-12 module on page no. 40 You will find the matching OMS-8 module on page no. 41
