Used for tightening and loosening bolts and nuts. ADJUSTABLE WRENCH (with GRADUATION)
The combination of the worm and the rack adjusts the opening
and closing of the mouth and can be used according to the size of
bolts and nuts. Scale Dimensions (mm) Qty./ Weight
Carton
A scale is attached to make it easy to adjust the size of bolts and Models display D A T L (Generally) (g)
(mm)
nuts in advance. MW-100 0～12 31.5 14.5 9 110 6 50
MW-150 MW-150 0～20 45.5 21.5 10 160 6 120
MW-200 0～25 58.5 25.5 13 206 6 240
MW-250 0～30 70.0 30.5 16 258 6 400
MW-300 0～35 82.0 35.5 18 304 6 650
MW-375 0～45 103.0 45.5 23 385 1 1,200
MW-200 MW-450 0～55 122.0 54.5 24 465 1 2,100

※ Dimension A is the maximum opening width.
※ The tilt angle of the mouth is 15°.
※ The opening angle is 22.5°.
MW-250

CAUTION
● Seize bolt/nut positively, without gap at full depth.

Suitable for speed work in narrow places such as machines, cars, ADJUSTABLE WRENCH SHORT TYPE
transport machines, furniture, office equipment, etc. Also can be
used at temporary tightening of bolts and nuts, and nut rotation
prevention when using adjustable type torque wrench. Models Dimensions (mm) Qty./Carton Weight
Store
D A T L H d (Generally) ( Center) (g)
MWS-24 46 24 9.5 113 23.5 8 6 6 80
MWS-36 66 37 13.5 148 32.0 8 6 6 210
MWS-46 93 46 16.5 187 33.4 8 6 6 455
MWS-24
※ Dimension A is the maximum opening width.
※ The tilt angle of the mouth is 15°.
※ The opening angle is 22.5°.

MWS-36
Example

CAUTION
● Seize bolt/nut positively, without gap at full depth.

For grabing things, turning pipes, cutting lines. COMBINATION SLIM PLIERS
The open mouth can be changed in two steps depending on the
size of the object. JIS Mark indication product.
Ideal for working in confined space since the slim tip. Cutting Dimensions (mm) Qty./ Weight
Carton
With thin head and asymmetric grasp blade, you can grasp firmly. Models Capacity A H T L (Generally) (g)
(mm)
Cut by 25% light force with center cut. CPS-200G 4 29 47 10.9 216 6 274.4
※ This product is registered design.
" )
-
5

Close
CPS-200G WARNING
● Wear goggles as chips disperse when cutting steel / copper cables.
CAUTION
● Beware not to pinch hand / finger. Hold the center of grip.
Wire rods
25% light force cutting.

WARNING
368 ● Plastic handle is not for insulation. Do not use on live lines.
