Anti-electricshock with electric insulated screwdriver.
Anti-electricshock with electric insulated screwdriver.

Telecommuniction, automobile, solar panel and other electrical works.

Safety insulated screwdriver AC1000V & DC1500V
confirmed with international standard IEC60900 and
VDE certification. 10kV dielectric routine test is performed
on all insulated screwdrivers before shipment.

Conducted under strict tests.

ELECTRIC INSULATED SCREWDRIVER An insulated screwdriver that protects user from electric shock,
providing safety while working.
Ideal tool for electrical works.
Models ELD7

Contents 7 Items (Insulated screwdriver : 1 / Electric testing screwdriver : 1)
Driver type ⊖ 0.5×3.0 ⊖ 0.8×4.0 ⊖ 1.0×5.5 ⊖ 1.2×6.5 ⊕ No.1 ⊕ No.2
Shaft length (mm) 100 100 125 150 80 100
Overall length (mm) 200 200 140 270 195 220
Weight (g) 45 45 77 114 70 102
● Packaged in a plastic case
● Weight : 1.3kg
● Qty./Carton : 1
※ Insulated screwdriver and electric testing screwdriver are not available for separate purchase.
※ Compatible up to AC 1000V, DC 1500V

ELD7

ELECTRIC TESTING SCREWDRIVER (PENCIL TYPE) No battery is required with neon light.
Compatible up to AC100-250V.
Touch the tip of the tester screwdriver to the wire. Then, contact
Driver type Shaft length Test range Weight the finger on the metal part at the end of the grip handle. The
(mm) (mm) (V) (g) neon will light up, notifying if the power is going to the circuit.
⊖ 0.5 × 3.0 70 100 ～ 250 23
※ The product is not available for separate purchase.

WARNING
● Please shut off an electrical circuit before operating.
● Please ensure that your working area does not reach over AC1000V , DC1500V.
● Please make sure to wear insulated gloves when operating.
● Insulation only applied on a grip and red color coated area.
● If any damage is noticed on the insulation coating or the tool body, stop using it immediately.
