Easy to hold and put a force on with T-shaped grip, increasing its T-TYPE GRIP NUT DRIVER (DEEP TYPE)
usability to the finest.
Most suitable for work that requires quick and continuous turning.
Across Dimensions (mm) Hexagonal
Flat
6 Models (mm) bolster two Qty./ Weight
side Width Carton
(g)
S D A1 A2 L φｄ (mm)
BTGW-08L 8 12 6 60 235 7 10 6 145
BTGW-10L 10 14 8 60 235 9 12 6 150
● Hexagon socket
WARNING
● Plastic handle is not for insulation. Do not use on live lines.

-
)FYBHPOBM
CPMTUFS
E
"
"
%
Recommended for automobile, bicycle, other
BTGW-08L BTGW-10L maintenance work! 4

Screwdriver for detaching hexagon bolt/nut. NUT DRIVER SET (DEEP TYPE)
Most suitable for deep and narrow space.

6 Models BD2

Contents 2 Items
BD2 Models BD- 08L 10L
Across Flat(mm) 8 10
● Hexagon socket
● Weight : 0.31kg
● Qty./Carton : 1

NUT DRIVER (DEEP TYPE)

Across Hexagonal
Flat Dimensions (mm) bolster two Qty./ Weight
Models (mm) side Width Carton (g)
S D A1 A2 L (mm)
BD-08L 8 12 6 60 260 10 12 150
BD-08L
BD-10L 10 14 8 60 260 12 12 160
● Hexagon socket
WARNING
● Plastic handle is not for insulation. Do not use on live lines.

BD-10L

WARNING
346 ● Do not misuse screwdrivers for wedge or chisel. Hammering or twisting damages screwdrivers and invite accident at a later date.
