Pro-Link EDGE HEAVY-DUTY VEHICLE DIAGNOSTICS
®
DIAGNOSTICS

®
Pro-Link Diagnostic Platforms
®
EEHD345MA*‡ Pro-Link Edge Master Kit with Cart
®
• Includes Pro-Link Edge Diagnostic Tool, full 10-pack
software suite, 6-pin Deutsch Cable, Data Cable, 9-Pin
Deutsch Cable, 16-Pin J1962 Cable, Crossover Cable, PLC
Adapter, Battery Pack, AC Adapter, Foam and Cart
• Over 500 programmable parameters to configure a fleet
to operating limits you define, e.g., idle shutdown,
speed limit, driver reward, engine rating, engine
protection shutdown and injector replacement
• (4) custom-fit foam drawer organizers with part number
and description labeling provide control for scan tool
and accessories (EEHDEKFOAM3A and EEHDEKFOAM4B
are for optional accessories)
• Cart split-top slides out from center to provide total
access to a generous top compartment, includes (4)
custom-fit foam drawer organizers with part number and
description labeling
• Whether in the driver’s seat or under the hood, the user
has the ability to view diagnostic data results via HDMI EEHD345SAPWZ
output to the 27ʺ HD LED monitor
• Print vehicle reports and information gathered from • USB port for accessories like a memory stick, keyboard
diagnostic sessions to a printer (purchased locally) that or printer
can be stored in the top drawer • Rugged solid state drive to store data and software
• All of the latest heavy-duty software is available, upgrades
including Cummins engines v.3.0 and Bendix • Choice of power sources: internal lithium-ion battery,
®
®
Air ABS v.2.0 120 V AC adaptor or vehicle adaptor
• Remote access for enhanced technical support • Get direct links from fault codes to step-by-step test and
• Tested and licensed OEM coverage for all major systems, diagnostic procedures, component locators and wiring
®
including engines, transmissions, ABS, instrument diagrams with the optional Repair-Connect
cluster, emissions, SCR, body controls and more • Internet delivery of software upgrades directly to the
• OEM-proprietary diagnostics for commercial vehicles tool and free trial period to try before you buy—see your
®
from light diesels to Class 8 heavy-duty trucks Snap-on representative to activate
• Perfect for truck shops, general repair, fleet maintenance • Software upgradable to accommodate new technology,
and municipalities ECUs and EPA requirements
• Essential maintenance functions: read and clear fault • Over 1,000 special tests to override vehicle controls
codes, access trip data to monitor vehicle and driver and operating conditions for diagnostic validation, e.g.,
performance, create health reports and view live data to DPF clean/replace, cylinder contribution, injector tests,
verify performance timing and boost calibration
• Powerful repair functions: graph live data to find tough
problems, special tests to verify component failures EEHD345SA** Pro-Link Edge Starter Kit
®
and validate system operation, program replacement • Includes Pro-Link Edge Diagnostic Tool, Starter Kit
®
components, expanded component diagnostics and Software, 6-pin Deutsch Cable, Data Cable, 9-Pin
custom ECU programming configuration Deutsch Cable, 16-Pin J1962 Cable, Battery Pack,
• Covers systems and components for the major AC Adapter, Soft Side Carry Case and Cart
®
®
®
heavy-duty manufacturers: Volvo , Mack , PACCAR , • Features a 10ʺ full-color class LED
®
®
®
Kenworth , Peterbilt , Freightliner , International and sunlight-readable display
®
more—plus light- and medium-duty truck coverage • Whether in the driver’s seat or under the hood, the user
• Common user interface for all makes has the ability to view diagnostic data results via HDMI
• Big, 10ʺ color touchscreen display for clarity and fast output to 27ʺ HD LED monitor
navigation automatically adjusts brightness for indoor • (4) custom-fit foam drawer organizers with part number
and outdoor use and description provide control for the unit and
Connectivity tools make it easy to save, view and share optional accessories
vehicle results: • Tool displays and keeps track of registered and trial
• HDMI port to view results on external monitor software titles
• SD memory card slot to store/share test results • Print vehicle reports and information gathered from
• Wi-Fi for networking diagnostic sessions to a printer (sold locally) that can
be stored in the top drawer
Colors Available:
Note: Color options require Flat Black Storm
an approximate 20-day lead Gloss Royal Ultra Electric Extreme Arctic Midnight w/Black Candy Gray w/
time for delivery Red Black Blue Yellow Orange Green Silver Blue Trim Apple Red White Black Trim
* PBO PC PCM PES PJK PJJ PKS PDG POT PJH — PWZ
** PBO PC PCM PES PJK PJJ PKS PDG POT PJH PU —
ADD SUFFIX TO STOCK NUMBER FOR SPECIAL COLORS
