FLUID MAINTENANCE: FLUID TRANSFER SERVICE EQUIPMENT
EQUIPMENT
Fluid Evacuators and Transfer Pumps
Easily remove engine oil, transmission fluid, coolant, brake and differential fluids. Unit creates a vacuum, providing a
clean, fast and simple way to evacuate or dispense a wide range of fluids. 8 L auto shutoff prevents overflow. 2.3 gal
(8.8 L) total capacity. Durable polyethylene construction is impervious to automotive and household chemicals.
®
VAC201 Manual Fluid Evacuator/Dispenser (Blue-Point )
• No electrical or compressed air is required
• Sturdy base with an exterior pump helps prevent tipping
• Complete system includes a manual, fluid evacuator, main hose
assembly (5/16 I.D. x 54ʺ long) and (2) rigid dipstick tubes for engine
oil removal
• 3/16ʺ I.D. x 34ʺ and 1/8ʺ I.D. x 34ʺ
VAC300 Pneumatic Fluid Evacuator (Blue-Point )
®
• Quiet operation results from an air muffler on the Venturi pump
• Unit can be used away from an air source by creating a vacuum,
closing both shut-off valves and transporting unit to the job
• Fluid evacuates by connecting the tubing and releasing the valves
• Complete system includes air-operated fluid evacuator with
Venturi pump and air shut-off valve on the base, a main pour spout
connector, main hose assembly (5/16ʺ I.D. x 58ʺ long) and a brake
VAC201 bleeding hose assembly with inline fluid control 1/4ʺ I.D. x 60ʺ long
and two rigid dipstick tubes for engine oil removal
VAC300
• 3/16ʺ I.D. x 34ʺ and 1/8ʺ I.D. x 34ʺ
®
FLUIDPUMP Fluid Transfer Pump (Blue-Point )
• Transfers or siphons all types of fluids, including coolant, oil,
SHOP FLUIDPUMP • Durable, non-corrosive polyethylene
transmission fluid and water
• Used to inflate sports balls, bicycle tires, flotation devices and more
• Includes a pump, (2) 4ʹ lengths of fluid hose, (2) intake/discharge
hose connectors, an air pressure hose, dipstick tube and dipstick/
fluid hose adaptor

LUBRICATION: OIL FILTER

YA4050B YA4250
YA4022

YA4275

YA4274A

®
Filter Pliers/Filter Sockets YA4250 Oil Filter Pliers (Blue-Point )
• Slip-joint design provides a jaw opening range of
YA4050B Oil Filter Pliers (Blue-Point ) 3-5/8–6ʺ
®
• Grips oil filters for easier removal • 12ʺ long
• Jaws are offset 20° from handle to increase accessibility ®
• Jaw opening range of 2-1/4ʺ–4ʺ YA4274A Oil Filter Pliers (Blue-Point )
• 12ʺ long • For use on filters 2-1/2–5-1/4ʺ diameter
• Offset handle offers increased accessibility
YA4275 ‡ Oil Filter Pliers (Blue-Point ) • Heavy-duty forged levers
®
• For use on filters 4-1/4–7ʺ (108–178 mm) diameter • Cushioned grips for comfort
• Spring action size adjustment assures a solid grip on • Industrial black finish
the filter • 13-1/2ʺ overall length
• Offset handle offers increased accessibility ®
• Heavy-duty forged levers YA4022 ‡ 23ʺ Long Reach Oil Filter Pliers (Blue-Point )
• Cushioned grips for comfort • Removes stubborn and overtightened oil, fuel and
• Industrial black finish hydraulic filters, plus fuel sending units and more
• 19ʺ overall length • Easy to maneuver around hot exhaust manifolds
• Applications include truck, tractor and high-torque • 23ʺ long, with tremendous holding power
diesel engines • 32 teeth jaws adjust to two sizes for an optimum grip
