COOLING: SERVICE TOOLS Hose Cutters and Removers
COOLING YA1000A YA1000A 9-5/8ʺ Multi-Cutter (Blue-Point ) ® ®

®
• Ideal for cutting heater hoses, fuel line hoses, copper wiring, PVC pipes,
wiper hoses and air brake hoses, plus any resilient or semi-resilient
material with a 0–1-1/8ʺ dia.
• Comfort contoured handles with plastic grips
• Wire loop for safe storage
• 9-5/8ʺ long
YA1000A1 Replacement Blade
• Replacement blade for the YA1000A Multi-Cutter
HCR1 Heater Hose Coupler Removal Tool (Blue-Point )
• Removes broken heater hose couplers on GM vehicles
• Can be used with an impact wrench
HCR1

Fan Clutch Wrenches/Pulley Holders
®
YA9521 Flat Wrench (Blue-Point )
YA9521 • 36/48 mm wrench size, 356 mm long
®
YA9325-1 Metric Flat Wrench (Blue-Point )
• 36 mm wrench size, 343 mm long
YA9980A Water Pump Fan Clutch Pulley Holder (Blue-Point )
®
• Used on vehicles with pressed on pulleys
®
• For use on 6.0 L V8 1999–later GM and 3.9 L V6, 4.7 L V8, 5.2 L V8,
5.9 L V8, 8.0 L V10 1998–later Chrysler ®
®
YA9325-1 • Cannot be used on Chrysler 4.7 L V8 using factory replacement
water pumps
YA6160 Universal Fan Clutch Pulley Holder (Blue-Point )
®
• Removes and replaces the fan clutch on vehicles using bolt-on
water pump pulleys
YA9980A • Reverse pulley holder is for assembly operations
• Use with the YA9521 36/48 mm wrench or YA9526 40 mm wrench for
®
®
many Chrysler , Ford , Lincoln , Mercury and GM applications
®
®
®
®
YA6210 Fan Clutch Wrench for BMW /Audi /VW Vehicles
®
®
®
(Blue-Point )
• 32 mm fan clutch wrench is used with the YA6160 Fan Clutch Pulley
Holding Tool to service 1996–later Audi vehicles, 1998–later 3.0 L V6
®
YA6160 ® ® ®
VW Passat , plus BMW 3, 5, 6, 7, 8, X and Z series vehicles
• YA6160 works on all models listed except 4.0 L and 4.4 L V8 engines
• Made from heat-treated steel
• 17ʺ (431.8 mm) overall length
®
FCT706 Fan Clutch Wrench (Blue-Point )
• Used for heavy-duty truck engines
YA6210 • Hole pattern on the tool aligns with fasteners on the fan hub
• Open end wrench is used to remove the fan clutch
• 24-1/2ʺ long for maximum leverage
®
YA6120 Fan Clutch Wrench Set (Blue-Point )
®
• Ford /Lincoln /Mercury applications include E-Series trucks
®
®
®
• 4.9 L (1984–1991), F-Series trucks 4.9 L (1984–1992), Bronco II and
®
®
Ranger 2.8 L (1984–1985), Ranger 2.9 L (1986–1992), Aerostar 3.0 L
®
®
®
®
(1986–1988), Aerostar and Ranger 4.0 L OHV (1990–later), Explorer
4.0 L OHV (1991–later), Mazda Navajo 4.0 L OHV (1991–1994), Mazda
®
®
B4000 4.0 L OHV (1995–later), Explorer 4.0 L V6 SOHC (1997–later) and
®
®
Mountaineer 4.0 L V6 SOHC (1998–later)
YA6120 • GM Applications: ASTRO and Safari vans 4.3 L, Blazer, Jimmy and
®
®
®
Bravada SUV 4.3 L, S10, Sonoma and Isuzu Hombre pickups with
®
®
2.2 L 4 cylinder and 4.3 L V6, C1500, C2500, C3500, K1500, C1500/
®
®
C2500/C3500/K1500 Sierra pickups, G1500/G2500 Chevrolet
®
Express, G1500/G2500 Savana vans 4.3 L V6, 5.0 L V8 and 5.7 L V8; and
®
®
®
®
Suburban , Tahoe , Yukon , Escalade , Denali and Envoy 5.7 L V8
®
®
FCT706
746
Snapon.com 1.877.762.7664
