STORAGE MOBILE SOLUTIONS: WORKSTATION
STORAGE

KEMW361 EPIQ Series Mobile Workstation
• Stainless steel work top (37 x 30ʺ) holds up to 1,000 lb
• Large 30ʺ deep case
• (5) large 30ʺ EPIQ InPulse drawers: (4) 4ʺ drawers and (1) 6ʺ drawer
™
• Swivel casters have rigid locking capability with a strong brake system
• EPIQ case design: top and bottom panel, and side walls absorb
heaviest load and impact
• Includes color-matched slotted accessory wall for mounting of shelves
and tool holders
Cubic Square Net Weight, Load Capacity,
2
3
Inches (cm ) Inches (cm ) lb (kg) lb (kg)
18,136 (297,195) 4,134 (26,691) 448 (203) 2,000 (907)
Width Depth Height
Drawers inches mm inches mm inches mm
4 30-1/16 764 27-1/2 700 4 101
1 30-1/16 764 27-1/2 700 6-3/16 157
Overall 37 940 30 762 42 1,067
KEMW361B1PBO
TOOL TOOL Red Gloss Royal Yellow Orange Colors Available Blk Trim Apple Red White Storm Gray
Five Total Drawers
KEMW361B1PBO EPIQ Series Mobile Workcenter

Candy
Ultra
Electric Extreme Arctic Midnight Flat Black
Blue
Green
Black
Blue
Silver
Blk Trim
PDG
PJK
PES
PJJ
POT
PKS
ROLL CARTS PBO PC PCM ADD SUFFIX TO STOCK NUMBER FOR SPECIAL COLORS PJH PU PWZ
KEMN361 EPIQ Series SideKIQ Roll Carts
™
• Super capacity in a maneuverable footprint—37ʺ wide and 30ʺ deep
• Same 48ʺ height as the EPIQ Roll Cab
• Deep 8ʺ top compartment is massive compared to everything else out
there—for large prybars, chargers, diagnostics, etc.
• (4) 7ʺ ISO-Ride+ swivel casters—all can be locked into rigid position
™
when desired
™
• InPulse drawer retention system is intuitive to use—more than three
times stronger than any other drawer retention system
• Six heavy-duty drawers hold 227 lb per drawer
™
• ISO-Ride+ torsion puck system anchors strongest, most stable
suspension system in the industry
• Casters are designed to carry 2,000 lb—each will provide a lifetime of
rugged use
• Lid styling and height blend with any EPIQ Roll Cab
• Radiused trim and inset drawers—no sharp corners
Cubic Square Net Weight, Load Capacity,
Inches (cm ) Inches (cm ) lb (kg) lb (kg)
2
3
26,125 (428,112) 6,027 (38,884) 498 (227) 2,000 (907)
Width Depth Height
Drawers inches mm inches mm inches mm
2 30-1/16 764 27-1/2 700 1-11/16 43
3 30-1/16 764 27-1/2 700 4 101
1 30-1/16 764 27-1/2 700 6-3/16 157
Top Compartment 36 914 29 717 8 203
Overall 37 940 30 762 48-3/8 1,229
Six Total Drawers
™
KEMN361B1PBO KEMN361B1PBO SideKIQ EPIQ Series Roll Cart
Colors Available
Gloss Royal Ultra Electric Extreme Arctic Midnight Flat Black Candy Storm Gray
Red Black Blue Yellow Orange Green Silver Blue Blk Trim Apple Red White Blk Trim
PBO PC PCM PES PJK PJJ PKS PDG POT PJH PU PWZ
64 64 ADD SUFFIX TO STOCK NUMBER FOR SPECIAL COLORS
