AIR LINE COUPLERS AND ADAPTORS

AHC23PMD AHC26D AHC25D AHC25FD POWER

AHC23MD AHC21MD AHC22MD AHC22FD

AHC28MD AHC31 AHC27MD TOOLS

Air Line Quick Couplers
Body Size, inches Style Thread Size Quick Coupler Male Quick Coupler Female Adaptor Male Adaptor Female
1/4 Lincoln ® 1/4ʺ-18 NPT — AHC26D ‡ AHC26MD ‡ AHC26FD ‡
1/4 Tru-Flate ® 1/4ʺ-18 NPT — AHC24D AHC24MD ‡ AHC24FD ‡
3/8 True-Flate ® 1/4ʺ-18 NPT — AHC25D ‡ AHC25MD ‡ AHC25FD ‡
1/4 ARO ® 1/4ʺ-18 NPT AHC23PMD ‡ AHC23D ‡ AHC23MD ‡ AHC23FD ‡
1/4 Industrial Interchange 1/4ʺ-18 NPT AHC21PMD ‡ AHC21D ‡ AHC21MD ‡ AHC21FD ‡
3/8 Industrial Interchange 1/4ʺ-18 NPT — AHC22E ‡ AHC22MD ‡ AHC22FD ‡
3/8 Industrial Interchange 3/8ʺ– 18 NPT — AHC28D ‡ AHC28MD ‡ AHC28FD ‡
1/2 Industrial Interchange 3/8ʺ– 18 NPT — — AHC31 ‡ —
1/2 Industrial Interchange 1/2ʺ-14 NPT — AHC27D ‡ AHC27MD ‡ AHC27FD ‡
1/4 Rigid Mounting 1/4ʺ-18 NPT — AHC21PD ‡ — —
1/4 Hi-Flow 1/4ʺ-18 NPT — AHCC98C ‡ AHCCP97C ‡ —
1/4 Hi-Flow HVLP 1/4ʺ-18 NPT AHCC91C ‡ AHCC90C ‡ — AHCC90C
*Conforms to Mil Spec MIL-C-4109F All adaptors are plated steel to improve durability.

Air Valves and Manifolds
IM10D Air Valve (Blue-Point )
®
• Volume of airflow can be regulated with 1/4 turn of the control knob
• Male/female thread sizes
®
AHC300 Multiline Air Manifold (Blue-Point ) IM10D AHC300
• Capacity of three air lines running at the same time
• Allows three workstations to use the same air supply
• Evenly distributes air through three different lines
