FLANK DRIVE COMBINATION
WRENCHES
OEX704B
OEX707B
OSH711B
Standard Handle, inches OSH711B* OSH713B* OEX714KB** OEX710* OEX707B* OEX703K2** OEX711B*
OEX703K1**
OEX704B**
OEX724KB**
OEX709B*
OSH707B*
A B C D E
1/4 — OEX8B 13/32 17/32 3/16 5/32 5 •
5/16 OSH10B OEX10B 1/2 21/32 7/32 5/32 5-3/4 • • •
11/32 OSH11B OEX11B 17/32 3/4 1/4 3/16 6-1/8 • •
3/8 OSH12B OEX12B 19/32 13/16 5/16 3/16 6-1/2 • • • • • • • • •
7/16 OSH14B OEX14B 21/32 29/32 5/16 7/32 7-1/4 • • • • • • • • •
1/2 OSH16B OEX16B 3/4 1-1/16 11/32 1/4 8 • • • • • • • • •
9/16 OSH18B OEX18B 27/32 1-3/16 3/8 9/32 8-3/4 • • • • • • • • •
5/8 OSH20B OEX20B 15/16 1-5/16 13/32 9/32 9-1/2 • • • • • • • • •
11/16 OSH22B OEX22B 1-1/32 1-13/32 7/16 5/16 10-1/4 • • • • • • • • •
3/4 OSH24B OEX24B 1-1/8 1-9/16 15/32 11/32 11 • • • • • • • • •
13/16 OSH26B OEX26B 1-3/16 1-21/32 17/32 3/8 11-3/4 • • • • • • •
7/8 OSH28B OEX28B 1-9/32 1-13/16 9/16 3/8 12-1/2 • • • • • • •
15/16 OSH30B OEX30B 1-3/8 1-29/32 19/32 13/32 13-1/4 • • • • • •
1 OSH32B OEX32B 1-15/32 2-1/32 21/32 7/16 14 • • • • • •
1-1/16 — OEX34B 1-9/16 2-3/16 11/16 15/32 14-3/4 • • •
1-1/8 — OEX36B 1-5/8 2-5/16 11/16 17/32 15-7/16 • • •
1-3/16 — OEX38B 1-3/4 2-7/16 3/4 1/2 16-5/16 • •
1-1/4 — OEX40B 1-13/16 2-9/16 3/4 17/32 17-1/16 • • •
1-5/16 — OEX42B 1-29/32 2-21/32 3/4 9/16 17-13/16 • •
1-3/8 — OEX44B 2 2-13/16 3/4 19/32 18-9/16 • •
1-7/16 — OEX46B 2-1/16 2-29/32 7/8 19/32 19-1/32 • •
1-1/2 — OEX48B 2-5/32 3-1/16 7/8 5/8 20-1/16 • •
1-9/16 — OEX50B 2-1/4 3-3/16 7/8 23/32 20-13/16 •
1-5/8 — OEX52B 2-11/32 3-11/32 7/8 11/16 21-9/16 •
1-11/16 — OEX54A 2-7/16 3-13/32 7/8 23/32 22-9/32
1-3/4 — OEX56A 2-17/32 3-9/16 1-1/32 23/32 22-7/8
1-13/16 — OEX58A 2-5/8 3-21/32 1-1/32 3/4 23-15/32
1-7/8 — OEX60A 2-11/32 3-13/16 1-1/32 25/32 24-1/32
2 — OEX64A 2-7/8 4-1/16 1-1/32 27/32 25-1/4
ASME B107.100 *Set includes storage tray.
®
OEX32B – OEX52B are full polished chrome. OEX54A – OEX64A are satin finish chrome. **Set includes storage bag.
Standard Handle,
GOEXM715 GOEXM715
mm, Industrial Set Set
Contains: Contains:
GOEXM715
A B C D E A B C D E
10 GOEXM100B 15 21 7 5 171 • 18 GOEXM180B 27 37 12 8 267 •
11 GOEXM110B 17 23 8 6 184 • 19 GOEXM190B 28 39 12 9 279 •
12 GOEXM120B 18 25 8 6 195 • 20 GOEXM200B 30 41 13 9 292 •
13 GOEXM130B 20 27 9 6 207 • 21 GOEXM210B 31 43 13 10 304 •
14 GOEXM140B 21 29 9 7 219 • 22 GOEXM220B 33 46 14 10 318 •
15 GOEXM150B 22 31 10 7 231 • 23 GOEXM230B 34 47 14 10 327 •
16 GOEXM160B 24 33 10 7 242 • 24 GOEXM240B 35 49 15 11 337 •
17 GOEXM170B 25 35 11 8 255 • 27 GOEXM270B 39 55 17 12 375
®
ASME /ANSI B107.100 Set includes storage tray.
®
