SPECIAL APPLICATION SOCKETS

209TFSMYA 3/8”
®
Twist, Shallow, inches/mm (Blue-Point ) 209TFSMYA 213TFSYA
• Twist sockets remove rounded/damaged fasteners Set
Contains:
A B C
3/8 TFSY121A 11/16 (17.5) 9/16 (14.3) — •
7/16ʺ (11) TFSY141A 11/16 (17.5) 21/32 (16.7) 1-1/4 (31.8) • •
1/2ʺ TFSY161A 3/4 (19.1) 3/4 (19.1) 1-1/4 (31.8) • DRIVE
9/16ʺ TFSY181A 13/16 (20.6) 13/16 (20.6) 1-1/4 (31.8) •
5/8ʺ (16) TFSY201A 29/32 (23.0) 29/32 (23.0) 1-1/4 (31.8) • •
11/16ʺ TFSY221A 31/32 (24.6) 31/32 (24.6) 1-3/8 (35.0) •
3/4ʺ (19) TFSY241A 1-1/16 (27.0) 1-1/16 (27.0) 1-3/8 (35.0) • •
10 TFSY10A 11/16 (17.5) 19/32 (15.1) 1-1/4 (31.8) • •
12 TFSY12A 11/16 (17.5) 11/16 (17.5) 1-1/4 (31.8) • •
13 TFSY13A 3/4 (19.1) 3/4 (19.1) 1-1/4 (31.8) • •
14 TFSY14A 13/16 (20.6) 13/16 (20.6) 1-1/4 (31.8) • •
15 TFSY15A 13/16 (20.6) 27/32 (21.4) 1-1/4 (31.8) • •
17 TFSY17A 31/32 (24.6) 31/32 (24.6) 1-3/8 (35.0) • •
Sets shown include storage tray. TOOLS

Twist, Deep, inches/mm
®
(Blue-Point ) 213TSFSYA Set 213TSFSYA
Contains:
A B C
3/8 TSFSY121A 11/16 (17.5) 9/16 (14.3) 2-1/8 (54) •
7/16ʺ (11) TSFSY141A 11/16 (17.5) 21/32 (16.7) 2-1/8 (54.0) •
1/2ʺ TSFSY161A 3/4 (19.1) 3/4 (19.1) 2-1/8 (54.0) •
9/16ʺ TSFSY181A 13/16 (20.6) 13/16 (20.6) 2-3/8 (60.3) •
5/8ʺ (16) TSFSY201A 29/32 (23.0) 29/32 (23.0) 2-3/8 (60.3) •
11/16ʺ TSFSY221A 31/32 (24.6) 31/32 (24.6) 2-5/8 (66.7) •
3/4ʺ (19) TSFSY241A 1-1/16 (27.0) 1-1/16 (27.0) 2-5/8 (66.7) •
10 TSFSY10A 11/16 (17.5) 19/32 (15.1) 2-1/8 (54.0) •
12 TSFSY12A 11/16 (17.5) 11/16 (17.5) 2-1/8 (54.0) •
13 TSFSY13A 3/4 (19.1) 3/4 (19.1) 2-1/8 (54.0) •
14 TSFSY14A 13/16 (20.6) 13/16 (20.6) 2-3/8 (60.3) •
15 TSFSY15A 13/16 (20.6) 27/32 (21.4) 2-3/8 (60.3) •
17 TSFSY17A 31/32 (24.6) 31/32 (24.6) 2-5/8 (66.7) •
Set shown includes storage tray.

DPFM12
Shallow, 10 pt

A B D E
12 DPFM12 18.3 18.3 26.9 7.1
DPFM12 3/8ʺ Drive 10-Point Metric 12 mm Shallow Impact Socket
®
®
®
• The DPFM12 is for clutch pressure plate bolts found on the flywheel assembly on Mitsubishi Eclipse and Dodge
Stratus vehicles
• Formed from tough alloy steel
• Heat treated to a lower hardness to add impact resistance and ductility
201
• Read safety precautions on pages W1 to W4
