METRIC HEX BIT SOCKETS

FADM8E 3/8”

Double Hex/Standard, mm, Chrome (3/8ʺ)
206EFABLM
• Double Hex Socket Drivers and Triple Square Socket
Drivers cannot be interchanged between applications
• Triple square hex sockets have 90° corners and double
Ball Hex/Long, mm, 206EFABLM hex bit sockets have 120° corners DRIVE
Chrome (3/8ʺ) Set • Using a Triple Square tool in a Double Hex application
Contains:
will strip the bolt head
• In general, Triple Square tools are used on European
A B vehicles and Double Hex tools are used on Asian vehicles
4 FABLM4E 129.3 FABLM4E2 • A B
5 FABLM5E 128.5 FABLM5E2 •
6 FABLM6E 128.5 FABLM6E2 • 8 FADM8E 18 FADM8E2
7 FABLM7E 128.5 FABLM7E2 • 8 FADM8LE 18 FADM8LE2
8 FABLM8E 127.3 FABLM8E2 •
10 FABLM10E 128.3 FABLM10E2 • FADM8E 3/8ʺ Drive Metric 8 mm Standard Double Hex
Set shown includes storage tray. Socket Driver
• Applications: Removal/installation of head bolts on
®
Toyota Tercel 1995 and later, and Paseo (1992–1997)
FADM8LE 3/8ʺ Drive Metric 8 mm Double Hex Long Bit TOOLS
Socket Driver
HEX BIT SOCKETS

GFA10E

212EFTAY 208EGFAY

Hex/Standard, inches (3/8ʺ) Set 208EFAY 208EGFAY
Contains:
Fits These Cap Fits These Set
A B
Screws Screws
1/8 FA4E GFA4E 2-1/16 TMA4E2 — 1/4ʺ • •
9/64 FA4.5E GFA4.5E 2-1/16 TMA4.5E2 #8 — • •
5/32 FA5E GFA5E 2-1/16 FA5E2 #10 5/16ʺ • •
3/16 FA6E GFA6E 2-1/16 FA6E2 1/4ʺ 3/8ʺ • •
7/32 FA7E GFA7E 2-1/16 FA7E2 — 7/16ʺ • •
1/4 FA8E GFA8E 2-1/16 FA8E2 5/16ʺ 1/2ʺ • •
5/16 FA10E GFA10E 2-1/16 FA10E2 3/8ʺ 5/8ʺ • •
3/8 FA12E GFA12E 2-3/32 SA12E2 7/16ʺ and 1/2ʺ 3/4ʺ • •
Sets shown include storage tray.
212EFTAY 12 pc Combination Drive SAE Standard Hex Driver Bit Socket Set
• Includes (12) 1/4 and 3/8ʺ drive Standard Hex Bit Sockets (1/16–3/8ʺ)

Hex/Stubby, Inches, Chrome (3/8ʺ)

A B
7/32 FAXS7E 1-5/16 FAXS7E2 208EFTAXSY FAXS10E
1/4 FAXS8E 1-11/32 FAXS8E2
5/16 FAXS10E 1-13/32 FAXS10E2 208EFTAXSY 8 pc Combination Drive SAE Hex
3/8 FAXS12E 1-15/32 FAXS12E2 Bit Stubby Socket Driver Set
Set shown includes magnetic storage tray. • Includes (8) 1/4 and 3/8ʺ drive Stubby Hex Bit
Sockets (1/8–3/8ʺ)
191
• Do not use chrome or industrial finish hand tools with impact drivers
• Read safety precautions on pages W1 to W4
