TORQUE ADAPTORS

• Precision crafted from special alloy steel and heat- • Design features radius edges that will resist
treated for optimum strength and durability damage/nicks
• Nickel-chrome finish helps protect against corrosion and • Center-to-center length on adaptor for easy 3/8”
makes it easy to wipe clean torque calculations
• Double hex (12-point) configuration allows socket to • Larger sizes feature thicker construction for strength
engage single hex fastener every 30° rather than every
60°, allowing for better access in restricted areas

208FRDH
208FRDHM Standard, Inches, Chrome (3/8ʺ) Set 208FRDH
Contains:
Standard, mm, Chrome (3/8ʺ) Set 208FRDHM Working A B C D E DRIVE
Contains:
Torque,
in-lb
Working
Torque, A B C D E 190 5/16 FRDH101 0.475 .750 1/4 7/16 2 •
in-lb 420 3/8 FRDH121 0.570 .750 5/16 7/16 2 •
212 — FRDHM8 12.1 19.1 6.2 10.9 50.8 500 7/16 FRDH141 0.655 .750 11/32 7/16 2 •
420 10 FRDHM10 17.1 18.8 7.8 11.0 50.8 • 710 1/2 FRDH161 0.740 .750 11/32 7/16 2 •
690 12 FRDHM12 18.8 18.8 8.2 11.0 50.8 • 1,050 9/16 FRDH181 0.825 .750 3/8 7/16 2 •
720 13 FRDHM13 21.0 18.8 7.8 11.0 50.8 • 1,400 5/8 FRDH201 0.890 .750 7/16 7/16 2 •
1,050 14 FRDHM14 21.0 18.8 9.4 11.0 50.8 • 1,400 11/16 FRDH221 0.989 .750 1/2 7/16 2 •
1,200 15 FRDHM15 25.1 18.8 7.8 11.0 50.8 • 1,400 3/4 FRDH241 1.080 .750 1/2 7/16 2 •
1,400 16 FRDHM16 22.6 18.8 11.0 11.0 50.8 • 2,000 7/8 FRDH281 1.28 3/4 7/16 7/16 2.0
804 17 FRDHM17 25.1 18.8 12.4 10.9 50.8 2,706 15/16 FRDH301 1.374 .750 7/16 7/16 2
1,400 18 FRDHM18 22.4 18.8 13.3 11.0 50.8 •
1,400 19 FRDHM19 27.4 18.8 13.3 11.0 50.8 • TOOLS
2,000 21 FRDHM21 30.9 18.8 10.9 10.9 50.8 Torque Adaptor
FTA35 3/8ʺ Drive Female/Male Torque Adaptor
• Manufactured from special alloy steel
• Precision machined and heat treated for optimum
strength and durability
FTA35 • 3.5ʺ center-to-center

SPLINE TORQUE ADAPTORS

Spline, Low-Profile, inches
• Precision crafted from special alloy steel FRESL24
and heat treated for optimum strength
and durability Working
• Nickel-chrome finish helps protect against Stock No. Torque, A B C D E
corrosion and makes it easy to wipe clean in-lb
• Unique spline wrenching configuration 7/16 FRESL14 224 3/4 (19.05) 3/4 (19.05) 3/16 (4.76) 7/16 (11.11) 2 (50.8)
can be used on ordinary 6- and 1/2 FRESL16 312 25/32 (19.84) 3/4 (19.05) 3/16 (4.76) 7/16 (11.11) 2 (50.8)
12-point fasteners 9/16 FRESL18 360 13/16 (20.64) 3/4 (19.05) 3/16 (4.76) 7/16 (11.11) 2 (50.8)
• Ideal for use with torque wrenches 5/8 FRESL20 480 29/32 (22.8) 47/64 (18.8) 3/16 (4.7) 7/16 (10.9) 2 (50.8)
• Will save time and avoid clearance issues 11/16 FRESL22 556 1 (25.1) 47/64 (18.8) 3/16 (4.7) 7/16 (10.9) 2 (50.8)
when working on propeller assemblies 3/4 FRESL24 465 1-5/64 (50.2) 3/4 (19.05) 7/16 (11.11) 3/16 (4.76) 2 (50.8)
®
• Works on a wide variety of Lycoming
®
and Continental engines used in Piper , 7/8 FRESL28 605 1-1/4 (31.75) 3/4 (19.05) 7/16 (11.11) 3/16 (4.76) 2 (50.8)
®
®
Cessna and Mooney aircraft 15/16 FRESL30 888 1-5/16 (33.9) 47/64 (18.8) 3/16 (4.7) 7/16 (10.9) 2 (50.8)
®
Spline, Inches, Chrome (3/8ʺ)
Working
Stock No. A B-B1 C-C1
Torque, in-lb
#7 7/32 FRES7 140 2 .375–.750 1/4–7/16
#8 1/4 FRES8 195 2 .400–.750 1/4–7/16
#9 9/32 FRES9 220 2 .445–.750 1/4–7/16
#10 5/16 FRES10 250 2 .490–.750 1/4–7/16
#12 3/8 FRES12 515 2 .590–.750 5/16–7/16
#14 7/16 FRES14 875 2 .680–.750 5/16–7/16
#16 1/2 FRES16 1,575 2 .745–.750 5/16–7/16
#18 9/16 FRES18 1,750 2 .825–.750 3/8–7/16 FRES10
#20 5/8 FRES20 1,750 2 .895–.750 3/8–7/16
#22 11/16 FRES22 1,750 2 .997–.750 1/2–7/16
#24 3/4 FRES24 1,750 2 1.08–.750 9/16–7/16
187
• Do not use chrome or industrial finish hand tools with impact drivers
• Read safety precautions on pages W1 to W4
