FLANK DRIVE SOCKETS

Deep, Inches, Chrome 110STMY Set 110STMY 110STMDY 1/4”
Contains:
A B C D E
1/8 STM04* STMD04 — — 7/32 7/16 1-21/32 2 1/8
5/32 STM05* STMD05 — — 1/4 15/32 1-21/32 2 3/16
3/16 STM6* STMD6* GSTM6 GSTMD6* 5/16 15/32 1-21/32 2 3/16 • •
7/32 STM7* STMD7* GSTM7 GSTMD7* 11/32 15/32 1-21/32 2 7/32 • •
1/4 STM8 STMD8 GSTM8 GSTMD8 3/8 15/32 1-21/32 2 7/32 • •
9/32 STM9 STMD9 GSTM9 GSTMD9** 13/32 15/32 1-21/32 2 1/4 • • STMD16
5/16 STM10 STMD10 GSTM10 GSTMD10** 15/32 15/32 1-21/32 2 7/32 • • DRIVE
11/32 STM11 STMD11 GSTM11 GSTMD11 1/2 15/32 1-21/32 2 9/32 • •
3/8 STM12 STMD12 GSTM12 GSTMD12 17/32 9/16 1-21/32 2 9/32 • •
7/16 STM14 STMD14 GSTM14 GSTMD14 5/8 9/16 1-21/32 2 3/8 • •
1/2 STM16 STMD16 GSTM16 GSTMD16 11/16 21/32 1-21/32 2 3/8 • •
9/16 STM18 STMD18 — GSTMD18 3/4 23/32 1-21/32 2 3/8 • •
GSTMD16
5/8 STM20A STMD20 — — 27/32 13/16 1-7/16 2 13/32
*Conventional hex Sets shown include magnetic storage tray.
**Larger bolt clearance diameter for servicing aerospace fastener

Long, mm, Chrome Set 102STMML
Contains:
A B C D E TOOLS
10 STMML10 14 13.2 33.0 101.6 7.4 • 102STMML
11 STMML11 15.2 14.6 30.6 101.6 9.4 •
Application:
For bumper cover bolts found on most European, Asian and US vehicles.
Shallow/Deep Sets, Inches, Chrome (1/4ʺ)
120STTM 20 pc 1/4ʺ Drive 6-Point SAE Flank Drive Shallow/Deep Socket Set
®
• Includes TM6–TM18 shallow sockets and STM6–STM18 deep sockets
• Includes (20 pc) 3/16–9/16ʺ 120STTM
• Includes magnetic storage tray
Shallow/Deep Sets, mm, Chrome (1/4ʺ)
®
124STTMM 24 pc 1/4ʺ Drive 6-Point Metric Flank Drive Shallow/Deep Socket Set
• Includes (24) shallow/deep sockets (5–15 mm)
• Includes magnetic storage tray 124STTMM
®
FLANK DRIVE LOW-PROFILE SOCKETS

110RTSMA 110RTSMA 112RTSMA 112RTMA
Low-Profile Socket Sets, mm
A B C D E
5 RTSM5 RTM5 7.7 12.1 7.7 17.7 2.2 • • •
5.5 RTSM5.5 RTM5.5 8.3 12.1 7.7 17.7 2.6 • • •
6 RTSM6 RTM6 9.3 12.1 7.7 17.7 2.7 • • •
7 RTSM7 RTM7 10.5 12.1 7.7 17.7 2.8 • • •
8 RTSM8 RTM8 11.5 12.1 7.7 17.7 3.6 • • •
9 RTSM9 RTM9 12.7 12.1 7.7 17.7 3.9 • • • RTM9
10 RTSM10 RTM10 14.0 12.1 9.4 19.0 4.7 • • •
11 RTSM11 RTM11 15.4 12.1 6.2 17.3 4.5 • • •
12 RTSM12 RTM12 16.5 12.1 6.1 17.8 4.9 • • •
13 RTSM13 RTM13 17.6 12.1 5.9 18.1 5.1 • • •
RTSM14
14 RTSM14 — 18.7 12.1 6.4 19.3 5.8
15 RTSM15 — 20.3 12.1 6.3 20.3 6.4
RAT72A — 11 mm Internal Hex Low-Profile • •
RTMBS8 — Magnetic Bit Holder for the Low Profile RAT72 • •
Sets shown include storage tray. RTSM15
137
• Do not use chrome or industrial finish hand tools with impact drivers
• Read safety precautions on pages W1 to W4
