HANDTORQUE® MULTIPLIERS

HANDTORQUE® HT3-1000 HANDTORQUE® HT3 SERIES

• 5:1 mean torque multiplication, accuracy ±4%
• 5:1 nominal torque multiplication, reaction dependant. Mean ratio • Supplied with two reaction bar styles for maximum versatility
with cranked foot is 4.8:1; with straight reaction is 4.9:1 • Robust construction means minimal maintenance and long life
• ±4% mean torque multiplication accuracy • Supplied in a carry case, the Highwayman is ideal for inclusion in the
• Small and compact design heavy vehicle tool kit
• Updated aesthetics with tough silver metallic powder coat • 1,300 N�m version has a spare ∕ 4" output square included in the kit
3
• Supplied with 2 reaction bar styles for maximum versatility • Multiplier head only (no reaction bars or plastic box) also available
• Quick-change cranked reaction with improved flexibility allowing 1,300 N�m version, part no. 17218
reaction in 8 orientations 2,700 N�m version, part no. 17219
• Robust construction means minimal maintenance and long life • If calibration is required, a UKAS accredited calibration certificate
• If calibration is required, a UKAS accredited calibration certificate may be ordered (at extra cost)
may be ordered (at extra cost) 2 HT3 SERIES
3
2 HT3-1000 17220 HT3 1,300 N�m Kit, ∕ 2" input x ∕ 4" output
1
3
180260 HT3-1000, 1,000 N�m Kit, ∕ 2" input x ∕ 4" output 17221 HT3 2,700 N�m Kit, ∕ 4" input x 1" output
1
3
Kits are supplied in a carry case with a reaction bar and a reaction foot
3
(17220 also contains a spare ∕ 4" sq� dr�)
Model HT3-1000 HT3 1,300 N·m HT3 2,700 N·m
Part Number 180260 17220 17221
Nominal 5:1 5:1 5:1
Mean Multiplication Ratio With Cranked 4�8:1 4.75:1 4.75:1
Reaction
With Straight
Reaction 4�9:1 5:1 5:1
ØD 65 108 108
H1 63 103 100
Dimensions (mm) R1 273 398 398
H2
44
21
36
L
77
85
55
83
R2 min�
R2 max. 143 140 140
212
212
R3 max. 240 344 344
Tool Weight (kg) 2�7 3�8 3�8
Reaction Cranked 0.5 1�36 1�36
Weight (kg) Straight 0�7 1�1 1�1
HT3 1300/2700
on right shown in
comparison with
HT3 1000

enquiry@norbar�com | www�norbar�com 50
