MarGear GMX 600 W

Universal Gear Measuring Center

DESCRIPTION

• The new GMX 600 W cylinder
coordinate measuring center
• The successful combination of
diameter, gear and form
measurement in one setup saves
on additional investment and
maintenance costs as well as
time
• Full functionality as gear or
cylinder coordinate measuring
center and form tester up to an
outside diameter of 600 mm
• The MarGear GMX 600W, as a
complete solution, can also be
used for measuring hydraulic
parts, crankshafts, camshafts
and pistons
• Combining gear measuring
tasks with various diameter,
form & position features has TECHNICAL DATA
never been easier. Due to high
precision scales and smooth GMX 600 W
drive units, even contour Measuring path X (mm) 300
measurements and waviness Measuring path Y (mm) 600
analysis are possible
• With over 6000 units sold, the Measuring path Z (mm) 700
MarWin environment is a clear Diameter max.* [mm] 600
and simple way ofcreating Mass [kg] 2250
complete programs in Teach In Max. workpiece weight [kg] 300 (on fixed base plate)100 (on centering and tilting table)
mode Accuracy Accuracy class I for gear measurement according to VDI/VDE 2612/2613 Group 1
• Improves programming efficiency at 20°C ±2°C
and reduces the possibility of Axial runout deviation (µm+µm/mm 0.07 µm + 0.0008 µm/mm
incorrectuse measuring radius)
• Proven GMX realtime machine Radial runout deviation (µm in table ≤ 0.1 µm
error correction is also used for height)
positioning movements with *max. diameter of spur gears
the new MarEcon control unit,
guaranteeing maximum speed
andprecision throughout the APPLICATIONS ACCESSORIES
entire measuring and movement Fully automatic testing of: • Probe arm changer (4 boxes)
sequenc • Diameter and distance • Anti vibration damping system
• The high-precision 3D • Straight and helical toothed cylindrical gears • XXL centering and tilting table (centering path up to
scanning sensor combined with • Synchronizing gear ± 72 mm)
fully automated swivelling unit • Form and location (also with centering and tilting • Tailstock 1000 mm
leads to highest flexibility even table)
regarding future measuring tasks • 3D geometries like line form
• The use of standardized
interfaces leads to universal • Optional: camshafts, crankshafts and pistons
communication in terms of
Industry 4.0. The following
interfaces are available:
• GDE interface for inner and
outer gears
• Data export to QS-STAT
• ASCII

For more information, please visit our website: www.mahr.com
