WORKSHOP TOOLS

Broken Screw Extractor and Drill-Bit Set

11310SQ
• Material : Drill-Bit(HSS), screw extractor(GCr15)
• Metal case size (mm) :149 x 115 x 24 (0.014 cuft) 10
PC.
Contents kg 0.4 1 / 40
ø2.5, ø3, ø4.5, ø6, ø8
M3 - M6
#1
1/8" - 1/4"
M6 - M8
#2 1/4" - 5/16"
#3 M8 - M11
5/16" - 7/16"
M11 - M14
#4 7/16" - 9/16"
#5 M14 - M18
9/16" - 3/4"
Speed Out Broken Screw Extractor Set

11406SQ

• For stripped, broken, stuck or damaged screw removal
• Size includes: #0, #1, #2, #2, #3, #4
• High hardness HSS material makes drilling easier and faster 6
• The screw extractor set is tested with quality, efficiency, PC.
durability and stability
g 82 12 / 96

Suitable for
Specifications Drill Size Screw Diameter
Ø H1
2.5 2-3mm
3.0 3-5mm
3.5 4-8mm
3.5 4-8mm
4.0 5-10mm
6.0 6-12mm
3 steps:

51.8mm
Extractor side Ø H1 HSS #2
Extracting out the damaged screw

Drilling side
Drilling a hole on screw head Drill a hole Reverse to Extracting the screw
another side
11015SQ

• Ideal tool for removing rounded/damaged/stuck bolts
• Material: 8660 steel 15
• Hardness: HRC49-52
PC.
g 0.53 1 / 20

Hex size(H) Size(S) Overall length(L)
mm inch mm mm
12 1/8", 3/16", 1/4", 3/8" 3, 4, 5, 5.5, 6, 8, 10 29
16 1/2" 11, 12, 14

• Operation:
• Drilling a hole which is 0.5mm bigger than the extractor on the bolt
• Insert the extractor in the bolt
• Turn counter clockwise to remove the bolt
Note: This is a manual operated tool, do not use with impact or power
tools
