SCREWDRIVERS &
L-WRENCHES & BITS
Power Driving

• Silicon chrome vanadium alloy steel (S2)
• Anti-rust oiled, phosphate sunk
• Magnetic
7150S
1/4" Hex size shank driver
order unit : one blister card • DIN ISO 2351-1

7100P Tip Tip Overall
• Short neck (9.5 mm) type KT NO. width thickness length g set
(mm)
(mm)
(mm)
• DIN ISO 2351-2
715003S1 3.0 0.5 50 6
715035S1 3.5 0.5 50 6
KT NO. No. Overall length g set 715004S2 4.0 0.5 50 7
50
7
715004S1
4.0
0.8
(mm)
715000P PH0 50 8 715045S1 4.5 0.6 50 7 10 / 150
715001P PH1 50 9 715005S1 5.0 0.8 50 8
715002P PH2 50 11 715055S1 5.5 0.8 50 8
715003P PH3 50 11 715006S1 6.0 1.0 50 8
715004P PH4 50 14 10 / 150 715065S1 6.5 1.2 50 9
716502P PH2 65 15
717001P PH1 70 16
717002P PH2 70 17
717003P PH3 70 17 7100T
719001P PH1 90 18 • For torx head screw
719002P PH2 90 20
719003P PH3 90 20
711002P PH2 100 24 10 / 120
711501P PH1 150 23
711502P PH2 150 33 KT NO. Overall length g set
711503P PH3 150 33 Size (mm)
715006T T6 50 5
715007T T7 50 5
7100H 715008T T8 50 5 5
715009T
T9
50
• DIN ISO 2351-3 715010T T10 50 6
715015T T15 50 6
715020T T20 50 7
KT NO. mm / inch Overall length g set 715025T T25 50 8 9
715027T
T27
50
(mm)
715002H H2 50 6 715030T T30 50 9
715025H H2.5 50 6 715040T T40 50 10
715003H H3 50 6 715050T T50 50 15 10 / 150
715004H H4 50 9 717006T T6 70 7
715005H H5 50 10 717007T T7 70 7
715006H H6 50 11 717008T T8 70 7
715007H H7 50 13 717009T T9 70 7
715008H H8 50 17 10 / 150 717010T T10 70 8
715012SH 3/16 50 20 717015T T15 70 8
715014SH 7/32 50 22 717020T T20 70 10
717002H H2 70 8 717025T T25 70 11
717025H H2.5 70 8 717027T T27 70 14
717003H H3 70 9 717030T T30 70 14
717004H H4 70 13 717040T T40 70 15
717005H H5 70 15 711110T T10 110 14
717006H H6 70 18 711115T T15 110 14
717008H H8 70 25 711120T T20 110 18
711102H H2 110 11 711125T T25 110 19
711125H H2.5 110 11 711127T T27 110 24
711103H H3 110 14 711130T T30 110 24
711104H H4 110 18 10 / 120 711140T T40 110 28
711105H H5 110 24 711506T T6 150 16
711106H H6 110 29
711107H H7 110 34 711507T T7 150 16 10 / 120
711108H H8 110 42 711508T T8 150 16
711110H H10 110 62 8 / 80 711509T T9 150 16
711502H H2 150 16 711510T T10 150 17
711503H H3 150 18 711515T T15 150 18
711504H H4 150 25 10 / 120 711520T T20 150 24
711505H H5 150 34 711525T T25 150 24
711506H H6 150 40 711527T T27 150 32
711508H H8 150 59 711530T T30 150 33
711540T T40 150 39
388
