Page 447 - HAZET英文2021

Specialty Tools Specialty Tools

Chassis – Cardan Shafts Chassis – Cardan Shafts

4925 Tool set for silent blocks 4925 Spindle set

Made in Germany C Made in Germany C
• Allows installing / removing directly on the vehicle • Motion screw thread at spindle and spindle nut cause high tractive and
compressive output with little effort (torque)
• Application: Silent block installation and removal
G • AUDI A3 model years 2003→2012 • Application: Use with tool set for double silent blocks HAZET 4925-2510/9
at the lower wishbone of the front axle
• 2-piece set:
SEAT Alhambra model year 2010 ∙ Altea model years 2004→2009 ∙
4925-11 spindle nut with axial groove bearing
León model years 2005→2012 ∙ Toledo model years 2004→2009 4925-67 spindle TR 14 x 2 mm
ŠKODA Octavia model years 2004→2010 ∙ Superb model years 2008→
VW Caddy model years 2004→2010 ∙ Eos model years 2006→ ∙
Golf 5/6 model years 2003→2012 ∙ Jetta model years 2005→2010 ∙
Passat model years 2005→2011 ∙ Scirocco model years 2008→ ∙
Touran model years 2003→2010 ∙ Tiguan model years 2007→ ∙
Sharan model years 2008→
• Pre-centring of the silent block allows damage-free installation
F • No extensive installation at the workshop press necessary 1 K è 4
• Easy operation with mechanical spindle HAZET 4929-1/3 (optional)
• Tool set for silent blocks, contents: 4925-67/2 259 2 194940
4925-54 ∙ 55 ∙ 56 ∙ 57
4925 Adapter
Made in Germany C
• Adapters for housing 4930-721
D

1 4

4925-69 199365
R 4929 Spindle set

Made in Germany C
• Operation of the tool sets for silent blocks
4925-2504/9 ∙ -2506/16 ∙ -2509/4
4929-2901/4 ∙ -2902/3 ∙ -2903/2 ∙ -2904/4
• Motion screw thread at the spindle and axial groove bearing at the pressure piece
cause high tractive and compressive output by low expenditure of force (torque)
• 3-piece set, contents:
1
C 4925-2509/4 è 4 4929-1 spindle TR 12 x 1.5
4929-2 compression nut with axial bearing Ä 24
4929-3 hexagon nut
4
191116
4925 Tool set for double silent blocks
Made in Germany C
• Removal and installation of the double silent block
in the aggregate carrier 1 K è 4
O • AUDI: A3 ∙ Q3,TT model year 2003 → 4929-1/3 225 3 156900
SEAT: León ∙ Altea ∙ Alhambra model year 2004 →
ŠKODA: Octavia ∙ Superb,Yeti model year 2004 →
VW: Caddy ∙ Golf 5-6 ∙ Jetta ∙ Sharan ∙ Scirocco ∙ Cardan Shafts
Eos ∙ Touran ∙ Tiguan model year 2003 →
• Operation with HAZET spindle set 4925-67/2 (optional)
2584 Screwdriver socket
Made in Germany F b8
A • Application: Cardan shaft
screw connection (Ä 6 mm)
• Long design
• With knurling
• DIN 3124, ISO 2725-1

U

1 è 4 1 S M N F 4
4925-2510/9 9 194926 2584 6 32 70 23 017041
446 Valid until December 31, 2021 Components and spare parts from page 482 to 490
