Hand Tools

4 Range of sockets

1016 Reversible ratchet head 1015 Handle bar with sliding head

Made in Germany / 4 Made in Germany 4
• Number of teeth: 32 • Handle bar HAZET 1014 and sliding head 1015-1
• Opening angle: 11.25° • With locking pin retaining
• Shank with bolt for locking pin retaining, • Surface: chrome-
output with locking pin retaining plated, polished
• Surface: chrome-plated • DIN 3122
• DIN 3122, ISO 3315

1 K è 4
1 K 4 1015/2 500 2 001927

1016 165 001941
1015 Sliding head
Wear? – No problem! Made in Germany
• HAZET tools are manufactured to the highest • For handle bar HAZET 1014 or 1014 P 4 3 ⁄4
quality. During long intensive loading there is a • With locking pin retaining
certain level of wear even for high-quality tools.
• Surface: chrome-plated, polished
• For this reason, there are spare parts and • DIN 3122
replacement sets available for many of our tools.

1 4
Cost-saving – Sustainable – Resource-saving! K
For long-term pleasure with your HAZET tools 1015-1 60 001910

1014 Handle bar
1016 Replacement set Made in Germany
• For sliding head HAZET 1015-1 or ratchet head HAZET 1016
Made in Germany • With ball and locking pin retaining
• Number of teeth: 32 • Surface: chrome-plated
• Opening angle: 11.25° • DIN 3122

1 K 4
1014 500 001897

1 4 1000 Socket ∙ 6-point

• Replacement set for shift lever consisting of: Made in Germany
shift lever ∙ screws ∙ ball ∙ compression spring • Short design c9
For HAZET reversible ratchet 1016 ∙ 1016/2 • With knurling
For HAZET torque wrench 5145-3 CT ∙ 6132-1 CT ∙ 6143 CT ∙
6143-1 CT ∙ 6144 CT ∙ 6144-1 CT ∙ 6145 CT ∙ 6145-1 CT ∙ 6146-1 CT • With bolt for locking pin retaining
1016/6 001972 • Surface: chrome-
plated, polished
3
• Replacement set for ratchet wheel 20 = ⁄4″ i consisting of: • DIN 3124, ISO 2725-1
ratchet wheel ∙ pawl ∙ shift lever ∙ screws ∙ ball ∙ compression spring
For HAZET reversible ratchet 1016 ∙ 1016/2
For HAZET torque wrench 5145-3 CT ∙ 6132-1 CT ∙ 6143 CT ∙
6143-1 CT ∙ 6144 CT ∙ 6144-1 CT ∙ 6145 CT ∙ 6145-1 CT ∙ 6146-1 CT
1016/8 N 001989
* = Not according to DIN
1016 Reversible ratchet head with handle bar 1 K G H c 4
1000-19 * 52 28 33.2 14.5 000623
Made in Germany / 4 1000-21 52 31 33.2 14 000647
• Number of teeth: 32 1000-22 52 32 33.2 14 000654
• Opening angle: 11.25° 1000-24 52 34 36 16.5 000661
• Shank with bolt for locking pin retaining, output with locking pin retaining 1000-27 54 38 35 19.3 000678
• Surface: chrome-plated, polished 1000-30 55 42 36 21.5 000692
1000-32 58 44.5 36 24 000708
1000-33 59 46 36 24.5 000715
1000-34 60 47.5 36 25.5 000722
1000-36 61.5 49.5 38 26.5 000746
1000-38 * 65 52.5 39 29 000760
1000-41 68.5 55.5 39 32 000784
1000-42 * 70 57.5 41 32 000791
1000-46 73 62 44 34 000807
1 K è 4 1000-50 76 67 45 37.1 000814
82
73.5
45
40.8
1000-55 *
000821
1016/2 620 2 001965 1000-60 * 88 80 45 44.9 000838
