PROFESSIONAL PLUS STANDARD
Socket metric hexagon 10 [3/8"]

Art.-Group 120

▶ Metric socket for continuous use in industry, craft and
automotive
▶ Highest quality level for demanding users
▶ Exact fit and highest power transmission with less wear
▶ Optimized to durability and highest demands
▶ Precision and durability far beyond DIN/ISO standards
▶ High grip due to the circumferential knurling

Version Short Drive Size 10 [3/8"]
Material Chrome-vanadium steel Locking Drive Ball catch groove
Coating Chrome-plated and matt satin finished, with knurling Output Outside hexagon according to DIN 3124 / ISO 2725-1
Application Type Manually operated Norm DIN 3124 / ISO 2725-1 / DIN 3120 / ISO 1174
Drive Internal square according to DIN 3120 / ISO 1174
Plastic hanger
Size L mm D1 mm D2 mm t mm €/Pc. Art.-No. Size L mm D1 mm D2 mm t mm €/Pc. Art.-No.
6 25.5 9.3 17.0 7.0 3.61 200 060 16 25.5 22.0 20.0 13.0 4.10 200 160
7 25.5 10.9 17.0 7.0 3.61 200 070 17 25.5 23.4 20.0 13.0 4.24 200 170
8 25.5 11.8 17.0 8.0 3.61 200 080 18 25.5 24.5 20.0 13.0 4.55 200 180
9 25.5 13.4 17.0 8.0 3.61 200 090 19 25.5 25.6 21.0 14.0 4.84 200 190
10 25.5 14.6 17.0 8.0 3.61 200 100 20 25.5 26.8 21.0 14.0 5.29 200 200
11 25.5 15.9 17.0 8.0 3.61 200 110 21 25.5 27.9 22.0 14.0 5.43 200 210
12 25.5 17.0 17.0 8.5 3.61 200 120 22 25.5 29.6 22.0 16.0 5.75 200 220
13 25.5 18.4 17.0 8.5 3.93 200 130 23 25.5 31.2 22.0 16.0 6.18 200 230
14 25.5 19.6 18.4 13.0 3.93 200 140 24 25.5 32.0 22.0 16.0 6.33 200 240
15 25.5 20.9 19.0 13.0 4.10 200 150

PROFESSIONAL PLUS STANDARD
Extra deep socket metric hexagon 10 [3/8"]

Art.-Group 120

▶ Extra deep socket - ideal for tight areas or hard-to-reach
screws and bolts
▶ Highest quality level for demanding users
▶ Exact fit and highest power transmission with less wear
▶ Optimized to durability and highest demands
▶ Precision and durability far beyond DIN/ISO standards
▶ High grip due to the circumferential knurling

Version Long Drive Size 10 [3/8"]
Material Chrome-vanadium steel Locking Drive Ball catch groove
Coating Chrome-plated and matt satin finished, with knurling Output Outside hexagon according to DIN 3124 / ISO 2725-1
Application Type Manually operated Norm DIN 3124 / ISO 2725-1 / DIN 3120 / ISO 1174
Drive Internal square according to DIN 3120 / ISO 1174
Plastic hanger

Size L mm D1 mm D2 mm t mm €/Pc. Art.-No. Size L mm D1 mm D2 mm t mm €/Pc. Art.-No.
7 64 10.9 17.0 12.0 6.33 201 070 15 64 20.9 19.0 25.0 7.11 201 150
8 64 11.8 17.0 14.0 6.33 201 080 16 61 22.0 20.9 28.0 7.11 201 160
10 64 14.6 17.0 25.0 7.11 201 100 17 64 23.4 20.0 25.0 7.25 201 170
11 64 15.9 17.0 25.0 7.11 201 110 18 64 24.5 20.0 25.0 7.72 201 180
12 64 17.0 17.0 25.0 7.11 201 120 19 64 25.6 21.0 25.0 7.85 201 190
13 64 18.4 17.0 25.0 7.11 201 130 21 65 27.7 23.9 29.0 8.18 201 210
14 64 19.6 18.4 25.0 7.11 201 140 22 64 29.6 22.0 25.0 8.92 201 220
14 64 19.6 19.6 25.0 7.71 211 214
