Page 243 - 德国Projahn2022

PROFESSIONAL PLUS STANDARD
Hex keys BLUE EDITION magnetic for hexagonal screws with
ball head extra long version

Art.-Group 141

▶ Long version - ideal for working in hard-to-reach areas
▶ Integrated magnet in ball head (from 3 mm) - screws made of
steel adhere to the hex key
▶ Short limbs for transmission of high torques due to leverage
effect of long limbs
▶ Made of high quality S2 steel - low wear, high strength and
flexibility at the same time
▶ With ball head - screwing also possible in angular application
▶ Lasered key size easy visible for a long time L1
▶ High quality optic due to blue coating
▶ Non-slip surface for better grip

L2
Version Extra long, with ball head
Material S2-steel
Coating Chrome-plated and matt-satin finish, coated blue
Output For hexagon screws
Norm DIN ISO 2936
Plastic hanger
Size L1 L2 €/Pc. Art.-No. Size L1 L2 €/Pc. Art.-No.
1.5 mm 90 mm 14 mm 1.78 3 613-015 7 mm 190 mm 34 mm 4.80 3 613-070
2 mm 100 mm 16 mm 2.10 3 613-020 8 mm 200 mm 36 mm 4.92 3 613-080
2.5 mm 112 mm 18 mm 2.16 3 613-025 10 mm 224 mm 40 mm 6.26 3 613-100
3 mm 126 mm 20 mm 2.52 3 613-030 12 mm 250 mm 45 mm 11.96 3 613-120
4 mm 140 mm 25 mm 2.76 3 613-040 14 mm 280 mm 56 mm 18.26 3 613-140
5 mm 160 mm 28 mm 3.14 3 613-050 17 mm 320 mm 63 mm 25.40 3 613-170
5.5 mm 177 mm 35 mm 3.38 3 613-055 19 mm 360 mm 70 mm 36.76 3 613-190
6 mm 180 mm 32 mm 3.87 3 613-060

STANDARD
PLUS

PROFESSIONAL PLUS STANDARD
STANDARD

PLUS

PROFESSIONAL
PROFESSIONAL
Hex keys for hexagonal screws short model
Art.-Group 141

▶ Short version - ideal for working in narrow spaces
▶ Solid and low-wear due to hardened chrome-vanadium-steel
Version Short
Material Chrome-vanadium steel
Coating Chrome-plated and matt-satin finish L1
Output For hexagon screws
Norm DIN ISO 2936
L2

Without packaging
Size L1 L2 €/Pc. Art.-No. Size L1 L2 €/Pc. Art.-No.
1.5 mm 45 mm 14 mm 0.45 3601-1.5 7 mm 95 mm 34 mm 2.25 3601-7
2 mm 50 mm 16 mm 0.54 3601-2 8 mm 100 mm 36 mm 2.47 3601-8
2.5 mm 56 mm 18 mm 0.50 3601-2.5 10 mm 112 mm 40 mm 2.88 3601-10
3 mm 63 mm 20 mm 0.77 3601-3 12 mm 125 mm 45 mm 5.20 3601-12
4 mm 70 mm 25 mm 0.96 3601-4 14 mm 140 mm 56 mm 7.02 3601-14
5 mm 80 mm 28 mm 1.13 3601-5 17 mm 160 mm 63 mm 11.11 3601-17
5.5 mm 90 mm 35 mm 1.29 3601-5.5 19 mm 180 mm 70 mm 15.82 3601-19
6 mm 90 mm 32 mm 1.63 3601-6
H 241
