PROFESSIONAL PLUS STANDARD
VDE screwdriver 6-in-1 universal for cross-headed screws PH
and PZ

Art.-Group 145

Video

▶ Always the right tool: Screwdriver for 6 drives PH 1 - 2 - 3 and ▶ High power transmission due to optimized handle-design
PZ 1 - 2 - 3 ▶ No slipping of the hand even with oily hands because of a
▶ Space-saving alternative - ideal for servicing, service technician combination of soft and hard materials in the handle
or plumbers ▶ Optimized power transmission from handle to blade due to a
▶ Highest safety while working with electrical systems according continuous connection
to DIN EN 60900 and IEC 900 ▶ Suitable for professional use due to high-alloyed special steel
▶ Isolated VDE blades for safe working up to 1,000 Volt ▶ Durable and solid blade tip in terms of hardness and toughness
▶ Also safe in case of extreme operating conditions due to ▶ Less abrasion at the tip and screw due to a high quality blade tip
certified stability at -40°C ▶ Handy multicomponent handle in hexagonal form

Material Chrome-vanadium steel
Coating Phosphated L2
Output For Phillips and Pozidriv screws
Handle 2-components-plastic
Norm DIN EN 60900 / IEC 900
L1
Without packaging, hangable
Size L1 L2 €/Pc. Art.-No.
PH 1 - PH 2 - PH 3 - PZ 1 - PZ 2 - PZ 3 215 mm 100 mm 12.98 5105-1230

PROFESSIONAL PLUS STANDARD
VDE screwdriver for slotted screws

Art.-Group 145

▶ Highest safety while working with electrical systems according ▶ Optimized power transmission from handle to blade due to a
to DIN EN 60900 and IEC 900 continuous connection
▶ Isolated VDE blades for safe working up to 1,000 Volt ▶ Suitable for professional use due to high-alloyed special steel
▶ Also safe in case of extreme operating conditions due to ▶ Durable and solid blade tip in terms of hardness and toughness
certified stability at -40°C ▶ Less abrasion at the tip and screw due to a high quality blade tip
▶ High power transmission due to optimized handle-design ▶ Handy multicomponent handle in hexagonal form
▶ No slipping of the hand even with oily hands because of a
combination of soft and hard materials in the handle

Material Chrome-vanadium steel
Coating Phosphated L2
Output For slotted screws
Handle 2-components-plastic
Norm DIN EN 60900 / IEC 900
L1
Without packaging, hangable
Blade Width Blade Thickness L1 L2 €/Pc. Art.-No.
2.5 mm 0.4 mm 165 mm 75 mm 4.78 5 125-01
3.5 mm 0.6 mm 195 mm 100 mm 5.07 5 125-03
4.0 mm 0.8 mm 190 mm 100 mm 5.07 5 125-04
5.5 mm 1.0 mm 230 mm 125 mm 6.23 5 125-05
6.5 mm 1.2 mm 260 mm 150 mm 7.05 5 125-06
H 231
