PROFESSIONAL PLUS STANDARD
Torque wrench TORQUE-PROFI PLUS 3% tolerance

Art.-Group 121

▶ Mechanical two-way torque wrench ▶ Easy & safe torque adjustment
▶ Extremely robust and durable ▶ With quick release button and direction switch
▶ Acoustic and tactile automatic short path release ▶ Non-slip, ergonomic handle
▶ Incl. calibration certificate according to DIN EN ISO ▶ Safety ring to lock the adjustable value
6789:2003
Equipping Quick release button and direction switch
Toothing Rough, 48 teeth
Tolerance ±3%
Material Chrome-vanadium steel
Coating Chrome-plated and matt-satin finish
Output Outside square according to DIN 3120 / ISO 1174
Output locking Ball stop
Norm DIN 3120 / ISO 1174 / DIN EN ISO 6789

Attention: Please turn back to the smallest value of the wrench after each use!
Torque wrenches should be calibrated once a year. Simply use our calibration service. Please contact our !
costumer service at +49 (0) 60 74 / 69 666 - 66 or verkauf@projahn.de. For every calibration of a torque
wrench we will charge 39.90 €.

Description Range Output L mm Lf mm €/Pc. Art.-No.
Torque wrench 5 - 25 Nm 6.3 [1/4“] 245 195 199.30 394 270
Torque wrench 20 - 100 Nm 10 [3/8“] 410 329 203.50 394 271
Torque wrench 40 - 200 Nm 12.5 [1/2“] 520 435 216.80 394 272
Torque wrench 60 - 340 Nm 12.5 [1/2“] 610 525 250.00 394 273
Repair kit 394241/394260/394270 6.3 [1/4“] 12.95 394 241-1
Repair kit 394242/394271 10 [3/8“] 13.90 394 242-1
Repair kit 394240/394272 12.5 [1/2“] 20.60 394 240-1
Repair kit 394243/394273 12.5 [1/2“] 20.60 394 243-1

Art.-no. 394240 page H 148

H 147
