PROFESSIONAL PLUS STANDARD
Bit socket for TX screws 12.5 [1/2"]

Art.-Group 120

▶ Bit socket for TX screws
▶ Highest quality level for demanding users
▶ Exact fit and highest power transmission with less wear
▶ Optimized to durability and highest demands
▶ Precision and durability far beyond DIN/ISO standards
▶ High grip due to the circumferential knurling

Material Chrome-vanadium steel / S2 steel Drive Size 12.5 [1/2"]
Coating Chrome-plated and matt satin finished, with knurling Locking Drive Ball catch groove
Application Type Manually operated Output For TX screws
Drive Internal square according to DIN 3120 / ISO 1174 Norm DIN 3120 / ISO 1174
Plastic hanger
Size L1 mm L2 mm D1 mm €/Pc. Art.-No. Size L1 mm L2 mm D1 mm €/Pc. Art.-No.
T10 60 20 22.5 7.40 335 010 T10 100 60 22.5 9.07 325 110
T15 60 20 22.5 7.40 335 015 T15 100 60 22.5 9.07 325 115
T20 60 20 22.5 7.40 335 020 T20 100 60 22.5 9.07 325 120
T25 60 20 22.5 7.40 335 025 T25 100 60 22.5 9.07 325 125
T27 60 20 22.5 7.40 335 027 T27 100 60 22.5 9.07 325 127
T30 60 20 22.5 7.40 335 030 T30 100 60 22.5 9.07 325 130
T40 60 20 22.5 7.40 335 040 T40 100 60 22.5 9.07 325 140
T45 60 20 22.5 7.40 335 045 T45 100 60 22.5 9.07 325 145
T50 60 20 22.5 7.40 335 050 T50 100 60 22.5 9.07 325 150
T55 60 20 22.5 7.40 335 055 T55 100 60 22.5 9.07 325 155
T60 60 20 22.5 7.40 335 060 T60 100 60 22.5 9.67 325 160
T70 60 21 25.0 10.89 335 070

PROFESSIONAL PLUS STANDARD
Bit socket for tamper TX screws 12.5 [1/2"]

Art.-Group 120

▶ Bit socket for tamper TX screws
▶ Highest quality level for demanding users
▶ Exact fit and highest power transmission with less wear
▶ Optimized to durability and highest demands
▶ Precision and durability far beyond DIN/ISO standards
▶ High grip due to the circumferential knurling

Version Short Drive Size 12.5 [1/2"]
Material Chrome-vanadium steel / S2 steel Locking Drive Ball catch groove
Coating Chrome-plated and matt satin finished, with knurling Output For tamper TX screws
Application Type Manually operated Norm DIN 3120 / ISO 1174
Drive Internal square according to DIN 3120 / ISO 1174
Plastic hanger
Size L1 mm L2 mm D1 mm €/Pc. Art.-No. Size L1 mm L2 mm D1 mm €/Pc. Art.-No.
T15 60 20 22.5 7.40 325 015 T40 60 20 22.5 7.40 325 040
T20 60 20 22.5 7.40 325 020 T45 60 20 22.5 7.40 325 045
T25 60 20 22.5 7.40 325 025 T50 60 20 22.5 7.40 325 050
T27 60 20 22.5 7.40 325 027 T55 60 20 22.5 7.40 325 055
T30 60 20 22.5 7.40 325 030 T60 60 20 22.5 7.40 325 060
