Universal socket 12.5 [1/2"]
Art.-Group 120

▶ Can be used as socket and screwing tool for hooks, wing nuts,
TX-, square drive and eyebolts
▶ Spring-mounted hexagonal pins adapt to many external profiles
▶ Multifunctional sockets
▶ Fits for metric and inch screw drives
▶ Space, time and weight saving alternative to conventional socket
sets in mobile use

Material Chrome-vanadium steel Locking Drive Ball catch groove
Coating Chrome-plated and matt-satin finish Output Various Video
Application Type Manually operated and electric screwdriver Norm DIN 3120 / ISO 1174
Drive Internal square according to DIN 3120 / ISO 1174
Plastic hanger
Drive Size Drive Output max. torque Nm L mm D1 mm D2 mm €/Pc. Art.-No.
12.5 [1/2“] 11-32 569 89 44.0 44.0 42.61 301 099

PLUS
PROFESSIONAL PLUS STANDARD
PROFESSIONAL

STANDARD

Stud extractor 12.5 [1/2"]
Art.-Group 120

▶ For thread-conserving installation and removal of stud bolts,
threaded rods and hanger bolts
▶ Suitable for right and left hand threads
▶ No damage to the thread in comparison to welding on auxiliary
materials or using pliers
▶ Turning without laboriously locking two nuts on the bolt
▶ Safe grip due to three internal rolls
▶ Use with square 1/2" or hex 21 mm wrench
▶ With external hexagon SW 24 mm (M14 - M16)

Material Chrome-vanadium steel Locking Drive Ball catch groove
Coating Chrome-plated and matt satin finished, with knurling Output Various
Application Type Manually operated and electric screwdriver Norm DIN 3120 / ISO 1174
Drive Internal square according to DIN 3120 / ISO 1174

Plastic hanger
Size max. torque Nm L mm D1 mm D2 mm €/Pc. Art.-No.
M6 20 Nm 60 24.0 23.0 12.46 301 906
M8 20 Nm 60 24.0 23.0 13.51 301 908
M10 33 Nm 70 28.0 23.0 14.55 301 910
M12 33 Nm 70 28.0 23.0 15.60 301 912
M14 45 Nm 72 30.0 26.0 27.43 301 914
M16 45 Nm 72 30.0 26.0 29.53 301 916
