VDE 1/2‘‘-SOCKETS AND ACCESSORIES

990
TORQUE WRENCH 1/2‘‘

³ with noticeable and audible „click“ mechanism
³ manually adjustable, double scale unit with Nm and ft.lb. 12,5
³ 2-colour-multilayer insulation (yellow, red)
for easy identification of insulation damages
³ accuracy +-4% of set value 1/2"
³ square drive according to DIN 3120-A 12,5, ISO1174,
with locking device
³ tested according to EN/IEC 60900, individually
tested with 10.000V and approved for 1.000V

Code Number Measuring range ft.lb. Measuring range Nm l/mm Pieces Weight/g
T U V
0990000001000 990 5-35 5-50 370 1 1140
972
VDE REVERSIBLE RATCHET 1/2‘‘

³ gear-wheel with safety locking mechanism and quick release button
³ 2-colour-multilayer insulation (yellow, red)
for easy identification of insulation damages
³ VDE insulated up to 1.000V,
according to EN60900/IEC 60900
³ ELORA-Chrome-Vanadium 31CrV3/1.2208 12,5
³ square drive according to DIN 3120-A 12,5,
ISO1174, with ball locking device 1/2"

Code Number l/mm Pieces Weight/g
T U V
0972000002100 972 260 1 690

971-... 07
VDE SOCKET 1/2‘‘
³ female square according to DIN 3120-C 12,5, ISO1174, with ball retaining groove
³ chrome-plated
³ 2-colour-multilayer insulation (yellow, red)
for easy identification of insulation damages
³ VDE insulated up to 1.000V, according to 12,5
EN60900/IEC 60900:2004
³ tested according to EN/IEC 60900,
individually tested with 10.000V and approved for 1.000V 1/2"
³ ELORA-Chrome-Vanadium 31CrV3 / 1.2208

Code Number w Length without isulation mm VDE GS Pieces Weight/g
U
V
0971000092100 971-9 9 40 - x 6 58
0971000102100 971-10 10 40 x x 6 60
0971000112100 971-11 11 40 x x 6 63
0971000122100 971-12 12 40 x x 6 64
0971000132100 971-13 13 40 x x 6 64
0971000142100 971-14 14 40 x x 6 63
0971000152100 971-15 15 40 x x 6 67
0971000172100 971-17 17 40 x x 6 74
0971000182100 971-18 18 40 x x 6 91
0971000192100 971-19 19 40 x x 6 83
0971000212100 971-21 21 40 x x 6 107
0971000222100 971-22 22 40 x x 6 114
0971000242100 971-24 24 40 - x 6 117
0971000272100 971-27 27 43 - x 6 181
0971000302100 971-30 30 45 - x 6 195
0971000322100 971-32 32 45 - x 6 200
