770-LT..., 770-LTA...
SOCKET 1/2", EXTRA DEEP, BI-HEXAGON

³ especially suitable for deep-set female screws on long threaded bolts
³ hot forged 12,5
³ chrome-plated, polished
³ knurled
³ ELORA-Chrome-Vanadium 31CrV3 / 1.2208 1/2"
³ female square according to DIN 3120-C 12,5, ISO 1174,
with ball retaining groove
³ according to DIN 3124, ISO 2725-1

l/mm d1 d2 Pieces Weight/g l/mm d1 d2 Pieces Weight/g 03
Code Number   Code Number  
T mm mm T mm mm
0770031002000 770-LT 10 80 15,1 23,0 6 104 0770132302000 770-LTA 1/2 80 18,9 23,0 6 130
0770031102000 770-LT 11 80 16,3 23,0 6 106 0770132402000 770-LTA 9/16 80 20,2 23,0 6 130
0770031202000 770-LT 12 80 17,7 23,0 6 108 0770031602000 770-LT 16 / 5/8 80 22,7 24,0 6 130
0770031302000 770-LT 13 80 18,9 23,0 6 122 0770132702000 770-LTA 11/16 80 24,4 23,0 6 140
0770031402000 770-LT 14 80 20,2 23,0 6 130 0770031902000 770-LT 19 / 3/4 80 26,6 23,0 6 155
0770031502000 770-LT 15 80 21,5 23,5 6 130 0770133002000 770-LTA 13/16 80 29,1 23,5 6 185
0770031602000 770-LT 16 / 5/8 80 22,7 24,0 6 130 0770133202000 770-LTA 15/16 80 32,9 24,3 6 220
0770031702000 770-LT 17 80 24,0 23,0 6 135 0770133402000 770-LTA 1 80 34,4 25,0 6 235
0770031802000 770-LT 18 80 25,5 23,0 6 155 0770032702000 770-LT 27 / 1.1/16 80 36,0 26,3 6 235
0770031902000 770-LT 19 / 3/4 80 26,6 23,0 6 155
0770032102000 770-LT 21 80 29,1 23,5 6 185
0770032202000 770-LT 22 80 30,4 24,0 6 190
0770032402000 770-LT 24 80 32,9 24,3 6 220
0770032702000 770-LT 27 / 1.1/16 80 36,0 26,3 6 235
0770033002000 770-LT 30 80 40,5 28,0 6 275
0770033202000 770-LT 32 80 43,0 29,0 6 325
0770033402000 770-LT 34 80 46,0 29,0 6 350

771-LT..., 771-LTA...
SOCKET 1/2", EXTRA DEEP, HEXAGON
³ especially suitable for deep-set female screws on long threaded bolts
³ hot forged 12,5
³ chrome-plated, polished
³ knurled
³ ELORA-Chrome-Vanadium 31CrV3 / 1.2208 1/2"
³ female square according to DIN 3120-C 12,5, ISO 1174,
with ball retaining groove
³ according to DIN 3124, ISO 2725-1

l/mm d1 d2 Pieces Weight/g l/mm d1 d2 Pieces Weight/g
Code Number Code Number
T mm mm   T mm mm  
0771031001000 771-LT 10 80 15,1 23,0 6 104 0771133001000 771-LTA13/16 80 29,1 23,5 6 185
0771031101000 771-LT 11 80 16,3 23,0 6 106 0771132701000 771-LTA11/16 80 24,4 23,0 6 155
0771031201000 771-LT 12 80 17,7 23,0 6 108 0771033802000 771-LT 38 / 1.1/2 80 51,5 27,5 6 375
0771031301000 771-LT 13 80 18,9 23,0 6 122
0771031401000 771-LT 14 80 20,2 23,0 6 130
0771031501000 771-LT 15 80 21,5 23,5 6 130
0771031601000 771-LT 16 80 22,7 24,0 6 130
0771031701000 771-LT 17 80 24,0 23,0 6 135
0771031801000 771-LT 18 80 25,5 23,0 6 155
0771031901000 771-LT 19 80 26,6 23,0 6 155
0771032101000 771-LT 21 80 29,1 23,5 6 185
0771032201000 771-LT 22 80 30,4 24,0 6 190
0771033802000 771-LT 38 / 1.1/2 80 51,5 27,5 6 375
