Page 426 - 日本前田TONE

Waterproof and dustproof makes it usable under harsh
environment such as wind, rain, and dust.

Waterproof Dustproof
（IPX7） （IP6X）

Washable in water.
Indicator light

● Chargable up to 2000 times. Green: High battery
● With AC100V-240V and DC12V-24V (in-vehicle use) Red: Low battery Green : Charge completion
● Indicator light when charging and remaining battery.
● Holder on the light body. Using Please charge. Charging
● When pressing the switch, the light will get brighter gradually, which will When the indicator light turns red, LED
protect eyes from sudden glare light. brightness will get lower. Continue to Red : Charging or using
● Hangable and placable on floor with attached holder. use without charging, the lamp will while charging.
● Washable in water. goes off after few seconds of flashing.

LED WORK LIGHT

Ideal for various situations such as night work, car maintenance, camping, and emergency lighting. Waterproof and
dustproof, making it usable even in harsh enviroment such as harsh wind, rain, or even sandstorm.
Consisted of side white LED x 30 (Both side : 30x2) and tip LED x 1.
Long-life battery that is rechargable up to 2,000 times.

With a holder installed to the
light body, making it hangable or
placable in various ways.

Product body

Example

❶ ❷
❶ The switch Accessory
❷ Charging port
Light LED Continuous LED Max. charge Number of Charging Charging Weight
Models Battery
source illuminance usage limits lifespan time rechargeable volt. current (g)
LiFeP04 White 1800 lux About 590
About
LT02WPC (lithium iron phosphate battery) LED 300 lumens 3 hours 100,000 3-4 hours 2000 DC5V 1,000mA Light body : 400
hours
times
3.2V / 2,000mAh built-in 66 （0.3m） (In case of 25 ℃) Holder : 190
Waterproof Dustproof Charging Operating Storage AC adapter Cigarette adapter
level level temp. range temp. range temp. range
IPX7 IP6X -5℃〜45℃ -20℃〜60℃ -20℃〜60℃ Input : AC100V-240V correspondence Input : DC12V-24V correspondence
(Output : DC5V/1,000mA)
(Output : DC5V/500-1,000mA)
Waterproof level IPX7 Protected against immersion in water up to 1m at normal pressure for 30 minutes. Various adjustable with
The light body With a holder installed flexible prop
Dustproof level IP6X Protected against 4 µm of dust.
※The charge temperature range indicates the battery temperature during charging. Hook (360°rotatable) Indicator lamp Drive box left/right
movable Hook (360°rotatable)
● Qty./Carton : 1 Accessory
Holder 1 Cigarette adapter 1
AC Adapter 1 Instruction manual 1

CAUTION
424 ● Do not use tool for purposes not intended.
